Design and principle of operation
Table4: Accessories for positioner attachment
Positioner Mounting instructions Order no.
Type3766-00(modelindex.02and
higher)
Direct attachment to the positioner
accordingtoFig.13(forpositionerwith
M20x1.5 electrical connection)
1400-6227
For older positioner models with
PG13.5
1400-6222
Type4765 NAMUR attachment to the yoke of a
controlvalveaccordingtoFig.14
1400-6223
Type3760 Attachment to the yoke of the
Type3510Micro-owValveaccording
toFig.15ortotheNAMURrib
1400-6224
Table3: Accessories for subsequent pressure gauge mounting
Pressure gauge Order no.
Pressuregauge:0.2to1.2barpressurerange 0080-0185
Pressuregauge:0to6barpressurerange 0080-0186
Pressuregauge:0to10barpressurerange 8520-0032
Pressuregauge:pressurerange0to0.6MPa/0to6kg/cm² 0800-0204
Forallpressuregauges:screwtting 0250-1090
