Samson Go Mic Mobile User Manual

Go Mic Mobile
14
Go Mic Mobile Mounting Instructions
Mounting Accessories
Insert Cover
Thumb Screw
Adjustable
Mounting Arm
Cold Shoe Adapter
Mounting Arm
Large Hook-and-
loop
1/4”-20 Mounting
Arm
Small Hook-and-
loop
1. Loosen the Lock Screw until the Adjustable Mounting Arm can be moved.
2. Position the receiver on the rear side of the smartphone.
3. Slide the Adjustable Mounting Arm so that it is tight with the edge of the
smartphone.
4. Apply pressure to the Adjustable Mounting Arm and tighten the Lock Screw.
Mounting to a smartphone

Samson Go Mic Mobile Specifications

General

Type	Radio microphone
RF power	10 mW
Microphone frequency	10 - 22000 Hz
Control type	Buttons
Product color	Black
Operating temperature (T-T)	-10 - 50 °C
Device interface	-
Connectivity technology	Wireless
Maximum operating distance	30 m
Power source	Battery
Battery life (max)	20 h
Battery technology	Alkaline
Number of batteries supported	2
Number of products included	1 pc(s)
