Samson Go Mic Mobile User Manual

Owner’s Manual
9
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANOPOLSKI
HXD2 Handheld Transmitter Callouts
1. Status Indicator - This LED displays
the operation mode.
2. Power/Pair Switch - Press <5 seconds
to turn the unit on or off. Press >5
seconds to enter pairing mode.
3. Battery Cover - Unscrew the battery
cover and slide down to open the
Go Mic Mobile Handheld battery
compartment.
4. Battery Holder - Open the battery
holder by pressing the tab and lifting
the cover. Insert two standard AA
(LR6) batteries here, being sure to
observe the plus and minus polarity
markings shown.
WARNING: Do not insert the batteries
backwards; doing so can cause
severe damage to the transmitter
and will void your warranty.
5. Input GAIN Control - This control
adjusts the transmitter input
sensitivity. This input sensitivity
control has been factory preset
to provide optimum level for the
particular microphone capsule
provided with the Go Mic Mobile
system and so we recommend that
this not be adjusted manually. If
necessary, however, you can use the
supplied plastic screwdriver to raise
or lower the input level.
6. Plastic Screwdriver - Used to adjust
the input GAIN control.
1
2
5
6
3
4

Samson Go Mic Mobile Specifications

General

Type	Radio microphone
RF power	10 mW
Microphone frequency	10 - 22000 Hz
Control type	Buttons
Product color	Black
Operating temperature (T-T)	-10 - 50 °C
Device interface	-
Connectivity technology	Wireless
Maximum operating distance	30 m
Power source	Battery
Battery life (max)	20 h
Battery technology	Alkaline
Number of batteries supported	2
Number of products included	1 pc(s)
