30
Accessories
The following accessories are supplied with the indoor unit.
The type and quantity may differ depending on the model.
Bushing bracket Insulation pipe Cable-tie Drain hose
User manual Installation manual Clamp
Selecting the installation location
Indoor unit
There must be no obstacles near the air inlet and outlet.
Install the indoor unit on a ceiling that can support its weight.
Maintain sufficient clearance around the indoor unit.
Make sure that the water draining from the drain hose runs away correctly and safely.
The indoor unit must be installed in out of public access. (Not touchable by the users)
Rigid wall without vibration.
Where it is not exposed to direct sunshine.
Where the air filter can be removed and cleaned easily.
• As a rule, the unit cannot be installed at a height of less than 2.5m (8.2ft).
• It is possible to install the unit at a height of between 2.2 ~2.5m (7.2~8.2ft) from the ground, if the unit
has a duct with a well defined length [300mm (11.8inch) or more] to avoid fan motor blower contact.
• If you install the cassette or duct type indoor unit on the ceiling with humidity over 80%, you must apply
extra 10mm (0.39 inch) of polyethylene foam or other insulation with similar material on the body of the
indoor unit.
CAUTION
