Disassembly and Reassembly
Samsung Electronics 3-73
No Parts Procedure Remark
1 Panel 1) Pull both hooks and take the grille
downward. Two safety clips are
mounted to the front grille to prevent
it from dropping.
2) Detach the safity clip and take up the
grille.
3) Remove the 2 fixed screws to remove
the Control-Box Cover.
(Use +Screw Driver)
4) Remove the remote control-receiver,
blade conector and humidity sensor
wires from the PBA. (4EA)
5) Push the 4 panel corners and cover
downwards to remove it.
■AC026RNNDKG,AC035RNNDKG,AC052RNNDKG,AC071RNNDKG
To Next Page
