Disassembly and Reassembly
Samsung Electronics 3-83
No Parts Procedure Remark
5) Release the 2 screws.
(one is top of the C-Box, the other is
left of it)
6) Release 2 Hold Wires and pull all wires
out from it .
3 Blowing &
Evap Part
1) Pull the Bracket Pipe(
ⓔ
)out.
2) Release 2 screws and pull Top
Discharge Kit(
ⓕ
) out.
ⓔ
ⓕ
