Disassembly and Reassembly
3-102 Samsung Electronics
No Parts Procedure Remark
12 Cabi Front RH 1) Purge the Coolant first.
2) Unscrew and remove 2 mounting
screws in Service Valve.
(Use +Screw Driver)
3) Separate the pipe from the Entrance/
Exit using a welder.
When removing the compressor,
Heat Exchanger, and Pipe, purge
the Coolant inside the Compressor
completely and remove the pipe with
a welding flame.
13 Cabi Top 1) Unscrew and remove 2 mounting
screws in Service Valve.
(Use +Screw Driver)
2) Separate the pipe from the Entrance/
Exit using a welder.
To Next Page
