Disassembly and Reassembly

Samsung Electronics 3-29

No. Parts Procedure Remark

2 Fan & Motor 1) Detach the screw and untie earth wire

of Motor.

2) Disconnect of housing of Motor Wire.

3) Disconnect the Capacity Wire.
