Disassembly and Reassembly

Samsung Electronics 3-33

No. Parts Procedure Remark

9) Loosen the screw what is fix with Base

Part and Drain Pan.

(Upper Sied:2EA)

0 ) Loosen the screw what is fix with Base

Part and Drain Pan.

(Lower Side:2EA)

1) Detach the Drain Pan completely.
