Disassembly and Reassembly

Samsung Electronics 3-43

No Parts Procedure Remark

5 Fan motor &

Cross fan

1) Unfasten the screw.

(use + Screw Driver)

2) Detach the FAN Motor case.

3) Unfasten the screw a little.

(use + Screw Driver)

4) Pull the CROSS-FAN to the left side.
