Disassembly and Reassembly
3-6 Samsung Electronics
No Parts Procedure Remark
4 Guard Cond 1) Detach the Sensor from the Guard Cond.
2) Loosen 4 fixing screws (CCW) on the
Gurad Cond. (Use +Screw Driver).
5 Cabi Back RH 1) Detach the Sensor from the Cabi-Back
RH.
2) Loosen 5 fixing screws (CCW) on Cabi-
Back RH. (Use +Screw Driver).
3) Pull the hook of Cabi Back RH
from the Bracket Valve.
To Next Page
