Disassembly and Reassembly
Samsung Electronics 3-11
No Parts Procedure Remark
2) Separate the Conpressor Felt Sound.
3) Loosen 3 nuts (CCW) at the bottom of
Compressor. (Use Monkey Spanner.)
When assembling Comp Wire, make sure
to match the color and location of the
wire with the picture.
15 Heat Exchanger 1) Loosen 2 fixing screws(CCW) on both
sides. And loosen 1 fixed screws(CCW)
Partition with base.(Use +Screw Driver.)
To Next Page
