Samsung AQV18VBAAQV24VBAAQV18VBC User Manual

Samsung Electronics 6-2
 MAIN PCB : DB93-05620B(cont.)
Location No. Code No. Description Specification Q’ty SNA/SA
R403 2007-000087 R-CHIP 6.8Kohm,5%,1/10W,TP,1608 1 SNA
R802 2007-000087 R-CHIP 6.8Kohm,5%,1/10W,TP,1608
1 SNA
R209 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608
1 SNA
R301 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608
1 SNA
R605 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608
1 SNA
R801 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608
1 SNA
R908 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608
1 SNA
R502 2007-000093 R-CHIP 20Kohm,5%,1/10W,TP,1608
1 SNA
R410 2007-000109 R-CHIP 1Mohm,5%,1/10W,TP,1608
1 SNA
R501 2007-000109 R-CHIP 1Mohm,5%,1/10W,TP,1608
1 SNA
R609 2007-000119 R-CHIP 560ohm,5%,1/10W,TP,1608
1 SNA
R101 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012
1 SNA
R102 2007-000493 R-CHIP 2.2Kohm,5%,1/8W,TP,2012
1 SNA
R106 2007-000872 R-CHIP 4.7Kohm,5%,1/8W,TP,2012
1 SNA
R105 2007-000931 R-CHIP 470ohm,5%,1/8W,TP,2012
1 SNA
R201 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216
1 SNA
R202 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216
1 SNA
R203 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216
1 SNA
R204 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216
1 SNA
R205 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216
1 SNA
R206 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216
1 SNA
R207 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216
1 SNA
R208 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216
1 SNA
R504 2007-000962 R-CHIP 5.1Kohm,1%,1/10W,TP,1608
1 SNA
R407 2007-001068 R-CHIP 6.8Kohm,1%,1/10W,TP,1608
1 SNA
R408 2007-001068 R-CHIP 6.8Kohm,1%,1/10W,TP,1608
1 SNA
R411 2007-001068 R-CHIP 6.8Kohm,1%,1/10W,TP,1608
1 SNA
C107 2201-000987 C-CERAMIC,DISC 2.2NF,20%,400V,Y5U,BK,12.5X6MM,10
1 SNA
C108 2201-000987 C-CERAMIC,DISC 2.2NF,20%,400V,Y5U,BK,12.5X6MM,10
1 SNA
C109 2201-002193 C-CERAMIC,DISC 0.082nF,?10%,3000V,SL,-,8.5 X 3,5
1 SNA
C502 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C503 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C504 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C505 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C506 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C507 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C508 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C509 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C510 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C102 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012
1 SNA
C201 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012
1 SNA
C202 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608
1 SNA
C203 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608
1 SNA
C204 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608
1 SNA
C401 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608
1 SNA
