Electrical Parts List
6-3
 MAIN PCB : DB93-05620B(cont.)
Location No. Code No. Description Specification Q’ty SNA/SA
C405 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608 1 SNA
C406 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608
1 SNA
C104 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
C106 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
C402 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
C403 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
C407 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
C501 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
C801 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
C901 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
XC71 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15
1 SNA
XC72 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15
1 SNA
CR71 2301-001363 C-FILM,LEAD-PPF 2000nF,+10-5%,450V,BK,38x18x30mm,33
1 SNA
C105 2401-000037 C-AL 470uF,20%,16V,GP,TP,8x11.5,5
1 SNA
C103 2401-000151 C-AL 1000uF,20%,25V,GP,TP,10x20,5
1 SNA
C601 2401-002300 C-AL 47?F,20%,50V,GP,TP,6.3x11,5mm
1 SNA
C101 2401-003895 C-AL 15uF,20%,450V,GP,TP,12.5x20mm,5
1 SNA
XTAL51 2802-001179 RESONATOR-CERAMIC 4MHZ,0.5%,BK,8X3X5.5MM
1 SNA
BZ61 3002-001129 BUZZER-PIEZO 85DB,-,-,2KHZ,-
1 SNA
SS71 3502-000115 SSR 12Vdc,-,2A,1mS,1mS
1 SNA
F701_1 3601-000263 FUSE-CARTRIDGE 250V,3.15A,TIME-LAG,GLASS,5x20mm
1 SNA
F702 3601-001209 FUSE-RADIAL LEAD 250V,1A,TIME-LAG,-,8.5x8mm
1 SNA
CN72 3711-000262 HEADER-BOARD TO CABLE 1WALL,3P,1R,7.92MM,STRAIGHT,SN,WHT
1 SNA
CN44 3711-000879 HEADER-BOARD TO CABLE BOX,3P,1R,2.5mm,STRAIGHT,SN,BLU
1 SNA
CN71 3711-003404 HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLU
1 SNA
CN80 3711-000941 HEADER-BOARD TO CABLE SMW250-04 YEL
1 SNA
CN91 3711-004352 CONNECTOR-HEADER SMW200-15 NTR
1 SNA
CN43 3711-004379 HEADER-BOARD TO CABLE BOX,4P,1R,2mm,STRAIGHT,SN,NTR
1 SNA
CN61 3711-004484 HEADER-BOARD TO CABLE BOX,5P,1R,2mm,STRAIGHT,SN,NTR
1 SNA
AC_L 3712-001139 CONNECTOR-TERMINAL TAB,MALE,-,6.35X0.8MM
1 SNA
ST11 DB26-00015A TRANS SWITCHING JT1916-09,
1 SNA
FT71 DB27-00017A COIL CHOKE USAV-07153,UU1116,15.0mH
1 SNA
CN21 DB39-01194A CONNECT WIRE-15P 26 AWG,-,15,140,WHT
1 SNA
PCB DB41-00526A PCB MAIN CEM-3,2,1.0,T 1.6mm,160*140mm
1 SNA
F701 DB61-00924A HOLDER-FUSE -,FH-51B,-,-,-,-,SSEC
1 SNA
IC04 DB91-00375A ASSY-MICOM INV Vivace2,MB90F823,sop,ROM,128K bytes
1 SNA
CN63 3711-000999 HEADER-BOARD TO CABLE SMW250-05 WHT
1 SNA
CN21 DB93-04257A ASSY PCB SUB COMM 485
1 SA
