Electrical Parts List
6-6
 INDOOR SUB PCB : DB93-04257A
Location No. Code No. Description Specification Q’ty SNA/SA
CD312 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB
1 SNA
IC31 0604-001003 PHOTO-COUPLER TR,50-150%,200mW,DIP-4,ST
1 SNA
IC20 0801-000393 IC-CMOS LOGIC 74HC86,OR GATE,SOP,14P,1
1 SNA
IC18 1006-001325 IC-BUS TRANSCEIVER 1487,SO,8P
1 SNA
R204 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608
1 SNA
R205 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608
1 SNA
R206 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608
1 SNA
R201 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608
1 SNA
R202 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608
1 SNA
R203 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608
1 SNA
R315 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608
1 SNA
R302 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012
1 SNA
R303 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012
1 SNA
R304 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012
1 SNA
R305 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012
1 SNA
R350 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012
1 SNA
R309 2007-000656 R-CHIP 27Kohm,5%,1/4W,TP,3216
1 SNA
R310 2007-000656 R-CHIP 27Kohm,5%,1/4W,TP,3216
1 SNA
R311 2007-000656 R-CHIP 27Kohm,5%,1/4W,TP,3216
1 SNA
R312 2007-000656 R-CHIP 27Kohm,5%,1/4W,TP,3216
1 SNA
C302 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C303 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608
1 SNA
C304 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012
1 SNA
C305 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012
1 SNA
C306 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012
1 SNA
C307 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012
1 SNA
C316 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,1608
1 SNA
RY01 3501-001248 RELAY-MINIATURE 12V,-,11.7MA,DPDT,4MS,4MS
1 SNA
CN31 3711-000015 HEADER-BOARD TO CABLE BOX,2P,1R,2.5MM,STRAIGHT,SN,WHT
1 SNA
CN12 3711-003847 HEADER-BOARD TO CABLE BOX,12P,1R,2mm,ANGLE,SN
1 SNA
CN11 3711-006040 HEADER-BOARD TO BOARD NOWALL,10P,2R,2.54mm,ANGLE,AU,BLK
1 SNA
PCB DB41-00528A PCB SUB CEM-3,2,1.0,1.6T,50*33,-,9,-,COMM 485
1 SNA
