Samsung Electronics
Electrical Parts List
6-7
OUTDOOR MAIN PCB : DB93-05544C
LOCATION CODE NO. DESC_SPEC PARA1 PARA2
18K 24K
SA/SNA
DB93-
05544C
DB93-
05544D
D451,D452,D4
53,D454,D455,
D456
0401-000133
DIODE-SWITCHING;RLS4148,75V,150mA,LL-
34,TP
RLS4148 100V/200mA
6 6 SNA
D102, D401,
D402, D403
0402-001429 DIODE-RECTIFIER;US1J,600V,1A,DO-214AC,TP US1J 600V/1A
4 4 SNA
D103, D104,
D105, D106
0402-001427 DIODE-RECTIFIER;ES1D,200V,1A,DO-214AC,TP ES1D 200V/1A
4 4 SNA
BD01 0402-001553
DIODE-
BRIDGE;GBPC3506W,600V,35A,SQUARE-4,BK
GBPC3506W
* 1 1 SNA
ZD451,ZD452,
ZD453,ZD501,
ZD502
0403-000258
DIODE-ZENER;MMBZ5232B,5%,225mW,SOT-
23,TP
MMBZ5232B 5.6V/225mW
5 5 SNA
CD31,CD32 0406-001109 DIODE-TVS;SAC5.0,7.6/-/-V,500W,DO-15 SAC5.0 7.6V/500W
2 2 SNA
D201 0407-000123
DIODE-ARRAY;DAN202K,80V,100mA,CA2-
3,SOT-23,TP
KDS184
* 1 1 SNA
Q904, Q905,
Q906, Q907
0504-000001
TR-DIGITAL;DTA114EKA,PNP,200mW,10K/
10K,SOT-23,TP
DTA114EKA 200MW
4 4 SNA
Q801 0504-000127
TR-DIGITAL;FJV3102RMTF,NPN,200MW,10K/
10K,SOT-23,T
FJV3102RMTF 200MW
1 1 SNA
IC51,IC52,IC53,
IC54,IC55,IC72
0506-000175 TR-ARRAY;2003,NPN,7,1W,SOP-16,ST,1000 ULN2003D013TR 1W
6 6 SNA
Q803 0508-001154 TR-IGBT; -,600V,80A,-,195W,TO-3P SGH80N60UF * 1 1 SNA
IC12,IC61,IC62 0604-001172 PHOTO-COUPLER;TR,100-300,200mW,SOP,TP TLP181-GRH-TPL 100-300% 3 3 SNA
IC30 0801-000393
IC-CMOS LOGIC;74HC86,OR GATE,SOP,14P,15
0MIL,QUAD,S
MM74HC86M SOIC-14
1 1 SNA
IC20 1006-001371 IC-BUS TRANSCEIVER ISL3175EIBZ * 1 1 SNA
IC21 1202-000104
IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL
,36V,CMO
KIA393F
* 1 1 SNA
IC16,IC19 1203-000274
IC-POSI.FIXED REG.;7805,TO-220,3P,-
,PLASTIC,4.8/5
KA7805A TO-220
2 2 SNA
IC13 1203-002948
IC-POSI.ADJUST REG.;TL431ACD,SOP,8P,4.9X3
.9MM,PLA
TL431ACD
* 1 1 SNA
IC59 1203-003334
IC-RESET;S-801,SOT-
23,5P,2.9x1.6mm,PLASTIC,3.716/
S-80142ANMC-
JC3-T2
* 1 1 SNA
IC11 1203-003527
IC-PWM CONTROLLER;TOP243,DIP,7P,9.83x6.
6mm,PLASTIC
TOP243PN
* 1 1 SNA
R107 2003-000708
R-METAL OXIDE(S);47ohm,5%,1W,AA,TP,3.3x9
mm
47-J 1W
1 1 SNA
R101 2003-000855
R-METAL OXIDE(S);47Kohm,5%,3W,AA,TP,6x1
6mm
47K-J 3W
1 1 SNA
R001 2006-001080
R-CEMENT(S);200ohm,5%,5W,CB,BK,13x9x25.
5mm
200-J 5W
1 1 SNA
R421 2006-001145 ASSY-R CEMENT 10m-J 15W 1 1 SNA
R401,R402,R40
3,R404,R405,R
406
2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 100-J 1/10W,1608
6 6 SNA
R504,R505,R50
6,R507,R553,R
606,R607
2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 330-J 1/10W,1608
7 7 SNA
R323, R342,
R808
2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 470-J 1/10W,1608
3 3 SNA
R103,R512,R55
7,R559,R601,R
604
2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1K-J 1/10W,1608
6 6 SNA
To Next Page
