Electrical Parts List
6-8
 OUTDOOR MAIN PCB : DB93-05544C(cont.)
R205,R208 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 2K-J 1/10W,1608 2 2 SNA
R104 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 3.3K-J 1/10W,1608 1 1 SNA
R315,R324,R32
5,R327,R328,R
407
2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 4.7K-J 1/10W,1608
6 6 SNA
R302,R303,R304,R
305,R306,R316,R5
09,R552,R554,R55
5,R556,R558,R560
,R561,R562,R563,
R566,R573,R574,R
805,R916,R917
2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 10K-J 1/10W,1608 22 22 SNA
R913 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 10K-J 1/10W,1608
0 0 SNA
R610 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 22Kohm 1/10W,1608 1 1 SNA
R510 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1M-J 1/10W,1608
1 1 SNA
R102 2007-000111 R-CHIP;6.8ohm,5%,1/10W,TP,1608 6.8-J 1/10W,1608 1 1 SNA
R408, R409,
R410
2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 33-J 1/10W,1608
3 3 SNA
R301 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608 120-J 1/10W,1608
1 1 SNA
R115 2007-000385 R-CHIP;14.3Kohm,1%,1/4W,TP,3216 14.3K-F 1/4W,3216 1 1 SNA
R502,R515 2007-000455 R-CHIP;18Kohm,1%,1/10W,TP,1608 18K-F 1/10W,1608 2 2 SNA
R706, R707,
R708
2007-000512 R-CHIP;2.4Kohm,5%,1/10W,TP,1608 2.4K-J 1/10W,1608
3 3 SNA
R807 2007-000553 R-CHIP;20ohm,5%,1/4W,TP,3216 20-J 1/4W,3216
1 1 SNA
R503, R514 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 24K-F 1/10W,1608 2 2 SNA
R112, R113,
R114
2007-000924 R-CHIP;470Kohm,1%,1/4W,TP,3216 470K-F 1/4W,3216
3 3 SNA
R412 2007-000929 R-CHIP;470ohm,1%,1/10W,TP,1608 470-F 1/10W,1608
1 1 SNA
R806 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 47-J 1/4W,3216 1 1 SNA
R511, R910,
R911, R912
2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608 5.1K-J 1/10W,1608
4 4 SNA
R907, R908,
R909
2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 8.2K-J 1/10W,1608
3 3 SNA
R900, R901,
R902, R903,
R904, R905,
R906
2007-001318 R-CHIP;1Kohm,5%,1/4W,TP,3216 1K-J 1/4W,3216
7 7 SNA
R201, R202,
R206, R207
2007-002667 R-CHIP;90.9Kohm,1%,1/4W,TP,3216 90.9K-F 1/4W,3216
4 4 SNA
R106, R203,
R204
2007-007342 R-CHIP;1.82Kohm,1%,1/10W,TP,1608 1.82K-F 1/10W,1608
3 3 SNA
R105 2007-007445 R-CHIP;9.09Kohm,1%,1/10W,TP,1608 9.09K-F 1/10W,1608
1 1 SNA
R116, R117,
R118
2007-008261 R-CHIP;150Kohm,1%,1/2W,TP,5025 150K-F 1/2W,5025
3 3 SNA
C307, C308,
C309, C310
2201-000154
C-CERAMIC,DISC;10NF,+80-
20%,2KV,Y5P,TP,20X5MM,7.5
10nF 2KV
4 4 SNA
C105,C106 2201-000322
C-CERAMIC,DISC;2.2NF,10%,2KV,Y5P,TP,13X5
MM,10
2.2nF 2KV
2 2 SNA
C903 2201-000322
C-CERAMIC,DISC;2.2NF,10%,2KV,Y5P,TP,13X5
MM,10
2.2nF 2KV
0 0 SNA
LOCATION CODE NO. DESC_SPEC PARA1 PARA2
18K 24K
SA/SNA
DB93-
05544C
DB93-
05544D
