Operating Instructions and InstallationElectrical Parts List
6-9 Samsung Electronics
 OUTDOOR MAIN PCB : DB93-05544C(cont.)
C201,C203,C2
04,C205,C301,
C451,C452,C4
53,C454,C455,
C456,C603,C6
07,C801,C900,
C901,C902,C9
07,C908,C567
2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608,- 10nF 50V,1608 20 20 SNA
C411,C412,C4
13,C414,C415,
C416
2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 1.2nF 50V,1608
6 6 SNA
C609 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,- 1nF 50V,1608
1 1 SNA
C108 2203-001414 C-CER,CHIP;330NF,10%,50V,X7R,TP,2012 330nF 50V,2012 1 1 SNA
C3011,C318,C
319,C320,C321
2203-002002 C-CER,CHIP;33pF,5%,50V,NPO,BK,1608,- 33pF 50V,1608
5 5 SNA
C419,C420 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,1608 22nF 50V,1608
2 2 SNA
C560, C561, C563, C565,
C568, C570, C575, C576,
C109, C112, C116, C117,
C121, C202, C302, C303,
C304, C305, C306, C404,
C405, C406, C407, C408,
C409, C410, C417, C418,
C501, C502, C503, C504,
C505, C506, C507, C508,
C509, C510, C511, C512,
C513, C553, C554, C706,
C555, C556
2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608,- 100nF 50V,1608 46 46 SNA
C113, C122,
C802
2203-005261 C-CER,CHIP;1000nF,10%,25V,X7R,-,3216 1000nF 25V,3216
3 3 SNA
C008 2301-000141
C-FILM,LEAD-
PEF;10nF,10%,630V,TP,16x11x7.5mm,5
10nF 630V
1 1 SNA
C422, C803 2306-000123
C-FILM,LEAD-
PPF;100nF,5%,630V,BK,26x16.5x8.5,2
100nF 630V
2 2 SNA
C123 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,5 100uF 25V 1 1 SNA
C104 2401-000470 C-AL;10uF,20%,450V,GP,TP,13x20mm,5m 10uF 450V 1 1 SNA
C552, C559,
C562, C564,
C569, C574,
C577
2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5 10uF 50V
7 7 SNA
C110, C119,
C805
2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5 220uF 25V
3 3 SNA
C107 2401-001552 C-AL;47uF,20%,35V,GP,TP,6.3x11,2.5 47uF 35V 1 1 SNA
C118, C401,
C402, C403
2401-002300 C-AL;47uF,20%,50V,GP,TP,6.3x11,5 47uF 50V
4 4 SNA
C114, C421 2401-002274 C-AL;220uF,20%,35V,WT,TP,8x11.5mm,5 220uF 35V 2 2 SNA
C101, C102,
C103
2401-003740 C-AL;560uF,20%,400V,WT,BK,35x50mm,10 560uF 400V
3 3 SNA
XTAL51 2802-001179
RESONATOR-
CERAMIC;4MHZ,0.5%,BK,8X3X5.5MM
4MHZ
* 1 1 SNA
XTAL 2802-001198
RESONATOR-
CERAMIC;10MHZ,0.5%,BK,8X3X5.5MM
10MHZ
* 1 1 SNA
RY03, RY04,
RY05
3501-001154
RELAY-MINIATURE; 12Vdc, 200mW, 3000mA,
1FormA, 10mS, 10m
PCJ-
112D3MH,501X
12Vdc,3A
3 3 SNA
RY31 3501-001248
RELAY-MINIATURE;12V,-
,11.7MA,DPDT,4MS,4MS
G6S-2 12V/2A
1 1 SNA
LOCATION CODE NO. DESC_SPEC PARA1 PARA2
18K 24K
SA/SNA
DB93-
05544C
DB93-
05544D
