Samsung Electronics 6-10
 OUTDOOR MAIN PCB : DB93-05544C(cont.)
RY01 3501-001268
RELAY-
POWER;12V,0.9W,25000mA,SPST,20mS,10mS
PCF-112D2M
* 1 1 SNA
CN34 3711-004182
CONNECTOR-
HEADER;BOX,10P,1R,2MM,STRAIGHT,SN,NTR
SMW200-10 NTR
1 1 SNA
CN29, CN61 3711-004484
CONNECTOR-
HEADER;BOX,5P,1R,2mm,STRAIGHT,SN
SMW200-05 NTR
2 2 SNA
REACTOR01,
REACTOR02
3712-001139
CONNECTOR-TERMINAL;TAB,MALE,-
,6.35X0.8MM
TAB YTR250
2 2 SNA
IC50 DB91-00577A IC MICOM,FORTE,VIVACE,MODERATO MB90F823 * 1 1 SNA
IC50 DB09-00338A
IC MICOM;MB90F823,-,80 P,5 V,24 MHz,STM-
0493-OA,-
MB90F823 STM-0493-OA
1 1 SNA
IC01 DB91-00532A
Montblanc1 OUTDOOR Inv
Micom,MN103SFA7K,80P, ROM Size: 256K
bytes
MN103SFA7K
* 1 1 SNA
IC01 DB09-00517A
IC MICOM;MN103FA7K,-,80P,+5V,10
MHz,Flash Memory,
MN103SFA7K
* 1 1 SNA
PT02 DB26-00075A
TRANS PULSE;PT_50,MH080FXEA4,10,65.5,8~
14,EI2218,
PT_50AM / EI22-
399N1
* 1 1 SNA
IC451, IC452,
IC453
DB32-00173A
SENSOR MAG-CT SENSOR;ASC712,5HP
INVERTER,-,-40~150
ACS712 30A
3 3 SNA
DB41-00627A PCB FR4
1 1 SNA
IC701 DB91-00557A EEPROM DATA 18K 512B
1 SNA
IC701 1103-001038
IC-EEPROM;93LC66,4KBIT,256X16BIT,SOP,8P,5
X4MM,-,2
93LC66B 512B
1 SNA
IC701 DB91-00558A EEPROM DATA 24K 512B
1 SNA
IC701 1103-001038
IC-EEPROM;93LC66,4KBIT,256X16BIT,SOP,8P,5
X4MM,-,2
93LC66B 512B
1 SNA
L/W COMM
485
DB93-04333B CONNECT WIRE #1015 22 AWG 5TURN
1 1 SNA
C/W COMP DB93-04335B CONNECT WIRE COMP #1015 14 AWG
1 1 SNA
YEL,BLU ,RED DB93-04338A CONNECT WIRE FAN -MOTOR UL1015 18#
1 1 SNA
L/W EARTH DB93-04344A CONNECT WIRE EARTH #1015 16 AWG 1 1 SNA
C/W 4 WAY DB93-04349A CONNECT WIRE 4WAY AS18BPBX 1 1 SNA
L/W POWER L DB93-04351A CONNECT WIRE L/W POWER L
#1015 AWG
14, BRN
1 1 SNA
L/W POWER N DB93-04351B CONNECT WIRE L/W POWER N
#1015 AWG
14, SKYBLU
1 1 SNA
IC81 DB95-00595A ASSY-PHOTO COUPLER;MH080FXEA4,- TLP250
* 1 1 SNA
IPM DB95-00954A ASSY-IPM;MH080EAV2A,MITSUBISHI IPM MH080EAV2A 21267
1 1 SNA
D101 DB98-16591A ASSY-DIODE RECTIFIER;FEP30JP FEP30JP * 1 1 SNA
LED2 DB98-16600A ASSY-LED GREEN;---------------------------------- TLPG5600 GRN 1 1 SNA
LED1 DB98-16601A ASSY-LED RED;---------------------------------- TLPR5600 RED
1 1 SNA
LED3 DB98-16602A ASSY-LED YEL;---------------------------------- TLPY5600 YEL 1 1 SNA
CN51 DB98-22298A
ASSY-HOOK WHT;INVERTER,SMAW250A-
04,RED
SMAW250A-04 RED
1 1 SNA
CN50 DB98-22299A
ASSY-HOOK WHT;INVERTER,SMAW250A-
04,WHT
SMAW250A-04 WHT
1 1 SNA
CN30 DB98-24921A
ASSY-CONNECTOR;AS-WB670X,SMAW250A-
06,WHT
SMAW250A-06 WHT
1 1 SNA
LOCATION CODE NO. DESC_SPEC PARA1 PARA2
18K 24K
SA/SNA
DB93-
05544C
DB93-
05544D
