installing the oven
Electrical installation of this appliance must be performed only by a licensed
electrician.
The oven must be installed according to the instructions supplied.
Remove the protective vinyl from the door after installation.
SAFETY INSTRUCTIONS FOR THE INSTALLER
• Installation must guarantee protection against exposure to electrically live parts.
•
The unit in which the appliance is fitted must satisfy the requirements of DIN 68930
in respect of stability.
INSTALLING INTO A CABINET
• Observe minimum clearance requirements.
• Secure oven into place with screws on either side of the oven.
• The oven should be slid into place at the proper angle of alignment.
min. 20
min. 50
50
460
595
595
560
572
545
21
90°
min. 550
min. 560
min. 600
High Cabinet
min. 550
min. 560
min. 590 ~ max. 600
50
Low Cabinet
