Specifications
Preset Timing Modes
This product can be set to only one resolution for each screen size to obtain the optimum
picture quality due to the nature of the panel. Therefore, a resolution other than the
specied resolution may degrade the picture quality. To avoid this, it is recommended that
you select the optimum resolution specied for the screen size of your product.
If a signal that belongs to the following standard signal modes is transmitted from your PC,
the screen will automatically be adjusted. If the signal transmitted from the PC does not
belong to the standard signal modes, the screen may be blank even though the power LED
turns on. In such a case, change the settings according to the following table by referring to
the graphics card user manual.
RESOLUTION
HORIZONTAL
FREQUENCY
(KHZ)
VERTICAL
FREQUENCY
(HZ)
CLOCK
FREQUENCY
(MHZ)
SYNC
POLARITY
(H/V)
VESA, 640 x 480 31.469 59.940 25.175 -/-
VESA, 800 x 600 35.156 56.250 36.000 +/+
VESA, 800 x 600 37.879 60.317 40.000 +/+
VESA, 1024 x 768 48.363 60.004 65.000 -/-
VESA, 1280 x 800 49.702 59.810 83.500 -/+
VESA, 1280 x 960 60.000 60.000 108.000 +/+
VESA, 1280 x 1024 63.981 60.020 108.000 +/+
VESA, 1440 x 900 55.935 59.887 106.500 -/+
VESA, 1600 x 1200 75.000 60.000 162.000 +/+
VESA, 1680 x 1050 65.290 59.954 146.250 -/+
VESA, 1920 x 1080 67.500 60.000 148.500 +/+
Horizontal Frequency
The time required to scan a single line from the left to the right side of the screen is called
a horizontal cycle. The reciprocal number of a horizontal cycle is called horizontal frequency.
Horizontal frequency is measured in kHz.
Vertical Frequency
Repeating the same picture dozens of times per second allows you to view natural pictures.
The repeat frequency is called "vertical frequency" or "refresh rate" and is indicated in Hz.
Specicationsofthedonglethat
connects to a PC - for Series 7 only
Standard UWB (Ultra Wide Band)
Host interface USB 2.0 downstream interface
Frequency range 3.1GHz – 10.6GHz (Operating at 3.16GHz – 8.97GHz, BG1, BG2,
BG6)
Security AES128
Data transmission rate 53.3 to 480 Mbps
Sensitivity/Power output Transmission signal PSD -41.3 dBm/MHz (limit: -41.3dBm/MHz)
Power consumption 1.18 watts (Typical), 4095-length packet, TFC1, Band Group 3,
480 Mbps
Supported models C24B750X / C27B750X
Dimensions 7 mm x 19 mm x 24.5 mm
