Alignment & Adjustment
3-6 Samsung Electronics
5. Video Adjust1
6. Video Adjust2
No Item Var./Fixed
Model
CL29M16MQ CL29M2MQ
CL29M21FQ
CL29T21FQ
1 R Cutoff Var. 20 20 20
2 B Cutof
f
Var. 49 49 49
3 R Drive Var. 29 29 29
4 G Drive Fixed 15 15 15
5 B Drive Var. 21 21 21
6 Sub Bright Var. 17 17 17
7 Sub Contrast Var. 7 7 7
8 PAL/SECAM Sub Color Fixed 23 23 23
9 NTSC Sub Color Fixed 21 21 21
10 NTSC Sub Tint Fixed 15 15 15
11 YUV Sub Tint Fixed 32 32 32
12 AKB Option Fixed 0 0 0
13 Peaking CFO & Delay Mode Fixed 1 1 1
14 Sub Sharpness-RF Fixed 10 10 10
No Item Var./Fixed
Model
CL29M16MQ CL29M2MQ
CL29M21FQ
CL29T21FQ
1 Melody Volume Fixed 25 25 25
2 RF AGC Var. 24 24 24
3 IF AGC Speed Fixed 1 1 1
4 VM Mode Fixed 0 0 0
5 VM Gain Fixed 0 0 0
6 VM Delay Fixed 0 0 0
7 Blue Stretch Fixed 0 0 0
8 G2 Adjust Bright Fixed 48 48 48
9 Soft Clipping Level Fixed 1 1 1
10 Peak White Limit Fixed 8 8 8
11 Cathode Drive Level Fixed 4 4 4
12 IF Demodulator Fixed 30 30 30
13 Fast Filter IF PLL Fixed 0 0 0
14 FOAB Fixed 3 3 3
