Samsung CL29K5MQ2X User Manual

Alignment & Adjustment
Samsung Electronics 3-7
7. Video Adjust3
8. Video Adjust4
No Item Var./Fixed
Model
CL29M16MQ CL29M2MQ
CL29M21FQ
CL29T21FQ
1 PIP Contrast Fixed 10 10 10
2 PIP Bright Fixed 4 4 4
3 PIP Tint Fixed 3 3 3
4 PIP Color Fixed 8 8 8
5 PIP YC Delay Fixed 12 12 12
6 PIP PAL V.Pos Fixed 1 1 1
7 PIP NTSC V. Pos Fixed 1 1 1
8 PIP H. Pos Fixed 2 2 2
9 PIP R Cutoff Fixed 7 7 7
10 PIP G Cutoff Fixed 6 6 6
11 PIP B Cutoff Fixed 7 7 7
12 PIP R Drive Fixed 139 139 139
13 PIP G Drive Fixed 152 152 152
14 PIP B Drive Fixed 142 142 142
15 PIP AGC Mode Fixed 3 3 3
No Item Var./Fixed
Model
CL29M16MQ CL29M2MQ
CL29M21FQ
CL29T21FQ
1 IF Preset Value 1 Fixed 32 32 32
2 IF Preset Value 2 Fixed 32 32 32
3 IF PLL Osc Preset Value Fixed 0 0 0
4 Preset Gain R Fixed 20 20 20
5 Preset Gain G Fixed 20 20 20
6 Preset Gain B Fixed 20 20 20
7 Turbo Center Frequency Fixed 0 0 0
8 DCXO Caps/NICAM Center Fixed 59 59 59
9 DCXO Scaning Control Gain Fixed 3 3 3
10 Component H-Shift Offset Fixed -4 -4 -4
