Samsung CT566BVX/STR

To Next Page

To Previous Page

REMARK

OPTION

FIX = “0”

OPTION

OPTION (MONO = 0)

OPTION (STEREO = 1)

Alignment and Adjustments

Samsung Electronics 3-5

3-2-3(B) OPTION BYTE 1

Table 3-3 Option Byte 1

DATA

FUNCTION

00 = TV/VIDEO

01 = TV/VIDEO/S-VIDEO

11 = NO ASSIGNED

0 = VID : 0

1 = VID : 1

0 = RB 10 STEP UP

1 = RB 5 STEP UP

0 = NO COMBFILTER

1 = COMBFILTER

0 = 4 : 3 CRT

1 = 12.8 : 9 CRT (Q MODEL)

0 = INTERNAL A/V SWITCH

1 = EXTERNAL A/V SWITCH

NOT USED

OPTION BYTE 1

Samsung CT566BVX/STR - Page 14
