Electric Parts List
Samsung Electronics 6-15
6-10 CT566BVX/STR (CT566BWX/STR AND CT566BVX/STR Dissimilar Parts)
ASSY-CABINET
* AA90-70091C ASSY-CABINET;566B,CT566BVX/STR
AA64-60052K INLAY-BACK;KCT57A,NT MONO,PS SHEET,T0.5,B
ASSY-CABINET,FRONT
* AA91-10329C ASSY-CABINET,FRONT;-,CT566BV,PA100,HB,BLK
AA64-31110B CABINET-FRONT;-,CT566BV,BK-708P EGN,HIPS,HB,
AA64-60278Q INLAY-AV;KCT57A,M/N GOLD,PS,T0.3,BLK,-,
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
6-11 CT566BVX/XAP (CT566BWX/STR AND CT566BVX/XAP Dissimilar Parts)
ASSY-PCB,MAIN
* AA94-10122L ASSY-PCB,MAIN(OPT);CT566BVX/XAP,KCT57A,PANAMA,-
C243 2301-000264 C-FILM,PEF;4.7nF,5%,50V,TP,6.5X5.5X3.0X5,
C650 2202-000222 C-CERAMIC,MLC-AXIAL;3.3nF,20%,16V,Y5P,TP,-,7.5
C651 2202-000222 C-CERAMIC,MLC-AXIAL;3.3nF,20%,16V,Y5P,TP,-,7.5
CM01 2202-000819 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V,TP,3.5x19
CN702 3711-002645 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,STRAIGHT,SN
JA701 3722-001192 JACK-RCA;2P(9P),3.4mm,SN,BLK,#16-22
JM07 2305-000288 C-FILM,MPEF;220nF,5%,50V,TP,7.3x4.8x5.5mm,
R245 2001-000273 R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m
R606 2001-000008 R-CARBON;15Kohm,5%,1/8W,AA,TP,1.8x3.2mm
WIRE1 AA65-30002ACLAMP-FBT;NYLON-66,V0,BLK,-,-,-
WIRE2 AA65-30009ACLAMP-FBT;ABS,V0,BLK,-,-,-
ASSY-PCB,A/V FRONT
* AA95-90027RASSY-PCB,A/V FRONT;-,CT566BVX/XAP,KCT57A,NTSC,100
3722-001282 JACK-RCA;2P(3P),3.2mm,AU,BLK,-
CN701B AA39-20055CLEAD-CONNECTOR,ASSY;-,YBNH025-06,67096-006,6P,500,
REMOCON
AA59-10095RREMOCON;-,TM59,RM322,24,L/GRY EX,SS
ASSY-CABINET
* AA90-70091DASSY-CABINET;566B,CT566BVX/XAP
AA64-60052KINLAY-BACK;KCT57A,NT MONO,PS SHEET,T0.5,B
ASSY-CABINET,FRONT
* AA91-10329CASSY-CABINET,FRONT;-,CT566BV,PA100,HB,BLK
AA64-31110BCABINET-FRONT;-,CT566BV,BK-708P EGN,HIPS,HB,
AA64-60278QINLAY-AV;KCT57A,M/N GOLD,PS,T0.3,BLK,-,
ASSY-ACCESSORY
AA68-30004AMANUAL-BOOK;-,W/P120(G),-,SEPA,-,-
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
