Samsung CT566BVX/STR - 6-6 VIDEO OUT OPTION; 6-7 MONO STEREO OPTION

Electric Parts List
Samsung Electronics 6-11
1 RA06 47K(2001-000786) DELETE
2 RA07 18K(2001-000411) DELETE
3 RA08 470(2001-000780) DELETE
4 RA09 150(2001-000362) DELETE
5 RA10 150(2001-000362) DELETE
6 RA11 1/2W 75(2001-001187) DELETE
7 CA01 25V 470uF(2401-001397) DELETE
8 CA02 25V 47uF(2401-001530) DELETE
9 QA01 C815Y(0501-000389) DELETE
10 QA02 A539Y(0501-000283) DELETE
11 JA701 3P OR 5P 6P(OR +SVHS PIN)
NO. LOC. NO. VIDEO OUT USED VIDEO OUT NOT USED
6-6 VIDEO OUT OPTION
1 C201 AX 25V 103(2202-000127) DELETE 1 CHIP PART
2 C214 P 50V 104(2305-000665) DELETE 1 CHIP PART
3 C231 P 50V 104(2305-000665) DELETE 1 CHIP PART
4 C243 50V 33 (CH)(2201-000487) P 50V 472(2301-000264) 1 CHIP PART
5 C622 25V 470 UF(2401-001397) DELETE CONTROL IC PART
6 C623 50V 0.47 UF(2401-001333) DELETE CONTROL IC PART
7 C624 50V 4.7 UF(2401-001271) DELETE CONTROL IC PART
8 C625 50V 2.2 Uf(2401-000660) DELETE CONTROL IC PART
9 C629 50V 10 UF(2401-000480) DELETE CONTROL IC PART
10 C630 50V 10 UF(2401-000480) DELETE CONTROL IC PART
11 C633 50V 4.7 UF(2401-001271) DELETE CONTROL IC PART
12 C650 AX 25V 152(2202-000106) AX 25V 332(2202-000222) CONTROL IC PART
13 C651 AX 25V 152(2202-000106) AX 25V 332(2202-000222) CONTROL IC PART
14 C701 50V 4.7 UF(2401-001271) DELETE AV SW,JACK PART
15 C702 50V 4.7 UF(2401-001271) DELETE AV SW,JACK PART
16 C703 50V 10 UF(2401-000480) DELETE AV SW,JACK PART
17 C706 50V 10 UF(2401-000480) DELETE AV SW,JACK PART
18 C708 16V 100uF(2401-001840) DELETE AV SW,JACK PART
19 C709 50V 10 UF(2401-000480) DELETE AV SW,JACK PART
20 C926 AX 25V 223(2202-000199) DELETE CONTROL IC PART
21 CD01 50V 10 UF(2401-000480) DELETE MTS PART
22 CD02 P 50V 104(2306-000122)) DELETE MTS PART
23 CD03 50V 10 UF(2401-000480) DELETE MTS PART
24 CD04 16V 47 Uf(2401-001496) DELETE MTS PART
25 CD05 50V 1 UF(2401-000603) DELETE MTS PART
26 CD06 p 63v 224(2305-000289) DELETE MTS PART
27 CD13 16V 100uF(2401-001840) DELETE MTS PART
28 CD27 P 50V 104(2306-000122)) DELETE MTS PART
NO. LOC. NO. STEREO(CT566BW) MONO(CT566BV) REMARK
6-7 MONO STEREO OPTION
