Samsung CT566BVX/STR - 6-15 CT566 BWX;STR Parts List

Electric Parts List
Samsung Electronics 6-19
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
6-15 CT566BWX/STR Parts List
ASSY-PCB,MAIN
* AA94-10122J ASSY-PCB,MAIN(OPT);CT566BWX/STR,KCT57A,PERU,-
C101 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
C102 2401-001363 C-AL;470uF,20%,16V,GP,TP,10x12.5mm,
C104 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V,TP,-,7.5
C105 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C106 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V,TP,-,7.5
C107 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C108 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C110 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C111 2202-000286 C-CERAMIC,MLC-AXIAL;56pF,5%,50V,SL,TP,1.9x3.5,-
C112 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V,TP,-,7.5
C113 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V,TP,-,7.5
C116 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V,TP,-,7.5
C117 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V,TP,-,7.5
C201 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V,TP,-,7.5
C202 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C203 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C204 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C205 2301-000223 C-FILM,PEF;22nF,5%,100V,TP,7.2x4.5x9.0mm,
C210 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C211 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C212 2202-000819 C-CERAMIC,MLC-AXIAL;47nF,+80-20%,50V,Y5V,TP,3.5x19
C213 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C214 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C219 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C220 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C223 2201-000144 C-CERAMIC,DISC;100pF,5%,50V,CH,TP,8x3,5
C224 2301-000264 C-FILM,PEF;4.7nF,5%,50V,TP,6.5X5.5X3.0X5,
C225 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C226 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C227 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C228 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
C229 2301-000201 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,5
C230 2202-000162 C-CERAMIC,MLC-AXIAL;15pF,5%,50V,SL,TP,3.5x19,-
C231 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm,
C232 2301-000264 C-FILM,PEF;4.7nF,5%,50V,TP,6.5X5.5X3.0X5,
C233 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11mm,5mm
C234 2309-000138 C-FILM,PE-PPF;100nF,5%,50V,TP,20x16x8.5,7.5m
C237 2305-000411 C-FILM,MPEF;470nF,5%,50V,TP,7.3x4.8x5.5mm,
C239 2401-000553 C-AL;1uF,10%,50V,HR,TP,5x11mm,5mm
C240 2201-000379 C-CERAMIC,DISC;22nF,+80-20%,50V,Y5V,TP,8.0X4.
C242 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C243 2201-000487 C-CERAMIC,DISC;33pF,5%,50V,SL,TP,5x3,5m
C244 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C253 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C301 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,1.9x3.5,-
C302 2305-000708 C-FILM,MPEF;150nF,5%,100V,TP,16.5x10.3x5.7
C303 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5,5
C304 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5,5
C305 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
C306 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16mm,5m
C307 2401-001569 C-AL;47uF,20%,50V,BP,TP,10x12.5mm,5
C308 2201-000108 C-CERAMIC,DISC;1.5nF,10%,1KV,Y5P,TP,11x5,5
C309 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
C401 2201-000599 C-CERAMIC,DISC;560pF,10%,500V,Y5P,TP,7x4,5
C402 2306-000329 C-FILM,MPPF;7nF,3%,1.6KV,TP,28.5x18.5x11mm
C404 2306-000187 C-FILM,MPPF;330nF,5%,400V,BK,26x20.5x13.5,
C405 2301-000213 C-FILM,PEF;220nF,5%,250V,TP,21.5x11,7.5
C406 2201-000556 C-CERAMIC,DISC;470pF,10%,500V,Y5P,TP,7x4,5
C407 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16mm,5m
C408 2201-000551 C-CERAMIC,DISC;470pF,10%,1KV,Y5P,TP,8x5,5
C409 2401-001661 C-AL;68uF,20%,100V,GP,TP,10x16mm,5m
C410 2401-002268 C-AL;2.2uF,20%,250V,LZ,TP,8X11,5
C411 2201-000556 C-CERAMIC,DISC;470pF,10%,500V,Y5P,TP,7x4,5
C412 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20mm,5m
C413 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5mm
C414 2201-000984 C-CERAMIC,DISC;680pF,10%,2KV,Y5P,TP,11x6,7.5m
C415 2303-000331 C-FILM,PPF;4.7nF,5%,630V,TP,19.5x12x7,7.5
C417 2301-000380 C-FILM,PEF;10nF,5%,50V,TP,6.5x3mm,5mm
C418 2401-001571 C-AL;47uF,+20%-0%,50V,GP,TP,8x12,5
C501 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5.7
C503 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5mm
C504 2202-000862 C-CERAMIC,MLC-AXIAL;390pF,10%,50V,Y5P,TP,3.5x1.9,-
C505 2202-000862 C-CERAMIC,MLC-AXIAL;390pF,10%,50V,Y5P,TP,3.5x1.9,-
C506 2202-000862 C-CERAMIC,MLC-AXIAL;390pF,10%,50V,Y5P,TP,3.5x1.9,-
C510 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m
C517 2201-000969 C-CERAMIC,DISC;10nF,+80-20%,3KV,Y5V,TP,-,10mm
C520 2202-000862 C-CERAMIC,MLC-AXIAL;390pF,10%,50V,Y5P,TP,3.5x1.9,-
C622 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16mm,5m
C623 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C624 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
C625 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C627 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11mm,5mm
C629 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C630 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C631 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11mm,5mm
C633 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
C634 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm
C635 2202-000295 C-CERAMIC,MLC-AXIAL;68pF,5%,50V,SL,TP,3.5x19,-
C636 2401-000947 C-AL;22uF,20%,35V,GP,TP,5x11mm,-
C650 2202-000106 C-CERAMIC,MLC-AXIAL;1.5nF,20%,16V,Y5P,TP,-,7.5
C651 2202-000106 C-CERAMIC,MLC-AXIAL;1.5nF,20%,16V,Y5P,TP,-,7.5
C701 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
C702 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
C703 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C704 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C705 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C706 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C708 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C709 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C801 2401-001140 C-AL;330uF,20%,400V,GP,-,35x45mm,10
C802 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250VAC,Y5U,TP,11x7,7
C803 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250VAC,Y5U,TP,11x7,7
C804 2201-002002 C-CERAMIC,DISC;4700pF,20%,400V,+20%~-55%,TP,2
C805 2201-000991 C-CERAMIC,DISC;560pF,10%,2KV,Y5P,TP,13x7,7.5
C806 2401-003026 C-AL;330uF,20%,200V,GP,ST,22x35mm,1
C807 2201-000599 C-CERAMIC,DISC;560pF,10%,500V,Y5P,TP,7x4,5
C808 2401-002288 C-AL;470uF,20%,25V,WT,TP,10x20,5
!
!
!
!
