Electric Parts List
Samsung Electronics 6-17
6-14 CT766DWX/STR (CT566BWX/STR AND CT766DWX/STR Dissimilar Parts)
ASSY-PCB,MAIN
* AA94-10128P ASSY-PCB,MAIN(OPT);CT766DWX/STR,KCT57A,PERU,-
* AA94-10126XASSY-PCB,MAIN(OPT);CT766DWX/XAP,KCT57A,PANAMA,-
C206 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C208 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C209 2305-000411 C-FILM,MPEF;470nF,5%,50V,TP,7.3x4.8x5.5mm,
C214 2301-000380 C-FILM,PEF;10nF,5%,50V,TP,6.5x3mm,5mm
C228 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C237 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C307 2401-003140 C-AL;47uF,20%,50V,WT/NP,TP,10x20,5
C402 2306-000237 C-FILM,MPPF;6.3nF,5%,1.6KV,TP,28.5x18x11.5
C404 2306-000204 C-FILM,MPPF;430nF,5%,400V,TP,26x20.5x12.5,
C417 2305-000178 C-FILM,MPEF;10nF,5%,100V,TP,-,5mm
C419 2306-000329 C-FILM,MPPF;7nF,3%,1.6KV,TP,28.5x18.5x11mm
C621 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5m
C801 2401-001426 C-AL;470uF,20%,400V,GP,-,35x45mm,10
C820 2401-003141 C-AL;2200uF,20%,25V,WT,TP,13x25,5mm
C822 2201-000963 C-CERAMIC,DISC;1nF,20%,400V,Y5U,TP,11x8mm,10m
C852 2401-002461 C-AL;220uF,20%,35V,GP,TP,10x12,5
C854 2305-000407 C-FILM,MPEF;470nF,5%,100V,TP,-,5mm
C856 2401-000903 C-AL;22uF,20%,160V,WT,TP,10x20mm,5m
CB01 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
CB19 2303-001026 C-FILM,PPF;33nF,10%,400V,TP,20x15x8,7.5
CB20 2306-000350 C-FILM,MPPF;270nF,5%,400V,BK,26x18.5x10,20
CF01 AA29-10002AFILTER-COMB;DP,UGL-357KNT,NTSC,ST
CN501A 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGHT,SN
CN502A 3711-002645 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,STRAIGHT,SN
D-COIL AA27-20003MCOIL-DEGAUSSING;-,29,14ohm,70T,L3300,E
D802 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D803 0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-
D807 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L,TP
D812 0402-000231 DIODE-RECTIFIER;FMG-G26S,600V,4A,TO-220F,ST
D816 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D825 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L,TP
DZ401 0403-000705 DIODE-ZENER;TZP8.2B,8.2V,8.2-9.3V,1W,DO-41
DZ803 0403-000697 DIODE-ZENER;TZP10A,10V,9.4-10.6V,1W,DO-41,
DZ806 0403-000656 DIODE-ZENER;MTZ15C,15V,14.35-15.09V,500mW,
DZ809 0403-000656 DIODE-ZENER;MTZ15C,15V,14.35-15.09V,500mW,
DZ810 0403-000299 DIODE-ZENER;MTZ7.5C,7.5V,7.29-7.67V,500mW,
DZ903 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ910 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
IC801 AA13-20002KIC-HYBRID;-,STR-S6709 LF953,SIP,9P,SMPS
IC851 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST
IC852 AA13-20004HIC-HYBRID;-,SE135N-LF12,TO220-LF12,3,ERR
L203 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,2400G
L401B AA27-30001GCOIL-LINEARITY;-,21uH,DR1415,PI0.7,4.5x30,-,2
L801 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5,TP,-
LB02 AA27-40003ACOIL-HORIZ,WIDTH;-,1mH,SB-5S 8x20,PI0.12,-
LE01 AA27-40003J COIL-HORIZ,WIDTH;-,3mH,ER14 20,PI0.35,ST
LK803 AA29-30002HFILTER-LINE NOISE;-,800uH,3.15A,80~280V,24-800uH
Q403 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6
Q801 0503-000153 TR-DARLINGTON;TIP102,NPN,2W,TO-220,TP,1000-2
Q802 0502-000244 TR-POWER;KSA940,PNP,1.5W,TO-220,-,40-14
Q803 0501-000366 TR-SMALL SIGNAL;KSC2330-Y,NPN,1W,TO-92L,-,70-1
Q804 0501-000366 TR-SMALL SIGNAL;KSC2330-Y,NPN,1W,TO-92L,-,70-1
R211 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm
R217 2004-001301 R-METAL;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R241 2004-001284 R-METAL;820Kohm,5%,1/8W,AA,TP,1.8x3.2m
R243 2001-000435 R-CARBON;1Mohm,5%,1/8W,AA,TP,1.8x3.2mm
R247 2004-001089 R-METAL;560Kohm,5%,1/8W,AA,TP,1.8x3.2m
R250 2001-000052 R-CARBON(S);3.3Kohm,5%,1/2W,AA,TP,2.4x6.4m
R301 2001-000006 R-CARBON;2.4Kohm,5%,1/8W,AA,TP,1.8x3.2m
R306 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x10mm
R309 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x10mm
R310 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10mm
R311 2003-002069 R-METAL OXIDE;470ohm,5%,2W,AF,TP,3.9x10mm
R404 2001-000117 R-CARBON(S);68ohm,5%,1/2W,AA,TP,2.4x6.4mm
R406 2003-002008 R-METAL OXIDE(S);18Kohm,5%,2W,AF,TP,3.9x10mm
R407 2001-001153 R-CARBON(S);47ohm,5%,1/2W,AA,TP,2.4x6.4mm
R409 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10mm
R411 2004-002022 R-METAL(S);51Kohm,1%,1/2W,AA,TP,2.4x6.4mm
R412 2004-001967 R-METAL(S);68Kohm,1%,1/2W,AA,TP,6.5x2.5mm
R413 2001-003019 R-CARBON(S);0.39ohm,10%,1/2W,AA,TP,2.4x6.4
R419 2008-001013 R-FUSIBLE(S);1.2ohm,5%,2W,AF,TP,3.9x10mm
R420 2008-000221 R-FUSIBLE;0.47ohm,10%,1/2W,AA,TP,4.7x11m
R801 2009-001011 R-METAL PLATE;0.18ohm,10%,5W,CL,TP,5x14x18mm
R802 2001-001117 R-CARBON(S);2Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R803 2001-001117 R-CARBON(S);2Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R812 2008-000204 R-FUSIBLE(S);0.22ohm,10%,1/2W,AF,TP,2.5x6.5
R814 2001-001117 R-CARBON(S);2Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R815 2006-000295 R-CEMENT;11ohm,5%,5W,CB,TP,9x13x25mm
R819 2003-000592 R-METAL OXIDE(S);22ohm,5%,2W,AF,TP,4x12mm
R823 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R824 2001-001164 R-CARBON(S);56Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R825 2001-001088 R-CARBON(S);1Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R851 2001-001143 R-CARBON(S);4.3Kohm,5%,1/2W,AA,TP,2.4x6.4m
R852 2001-001088 R-CARBON(S);1Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R853 2003-000592 R-METAL OXIDE(S);22ohm,5%,2W,AF,TP,4x12mm
R961 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm
RA01 2003-002102 R-METAL OXIDE;68Kohm,5%,2W,AF,TP,4x12mm
RA02 2003-002102 R-METAL OXIDE;68Kohm,5%,2W,AF,TP,4x12mm
RM901 AA59-60003SMODULE-REMOCON;-,ORC-50VFM/SR-12VM,38KHz,940m
RX04 2001-001149 R-CARBON(S);43Kohm,5%,1/2W,AA,TP,2.4x6.4mm
RX05 2004-001995 R-METAL;9.1Kohm,5%,1/8W,AA,TP,1.8x3.2m
T401 AA26-50001RTRANS-HORIZ DRIVE;-,80MH,580UH,4UH,G11A EI19,ST
T444 AA26-30005CTRANS-FLYBACK;-,FTH-29A013(S),29,130V
T801 AA26-20004E TRANS-SWITCHING;-,80-260V,-,ER534521,460uH,-,-
WIRE1 AA65-30002ACLAMP-FBT;NYLON-66,V0,BLK,-,-,-
WIRE2 AA65-30009ACLAMP-FBT;ABS,V0,BLK,-,-,-
ASSY-ACCESSORY
* AA39-40001BCABLE-RCA;-,RCA,1500mm,0.12/10,RED/WHT/Y
* AA68-30004AMANUAL-BOOK;-,W/P120(G),-,SEPA,-,- PANAMA
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
