Samsung CT566BVX/STR - 6-3 CRT PCB PART (TDA6101 Q IC)

Electric Parts List 6-8 Samsung Electronics
TXG2045 CT5072BVC/GE CT566BV/SAM TXG2545 CT6202BVC/MABY TXG2745 CT766DW/SEP
TXG2046 CT5372BVC/GE CT566BV/SEP TXG2547 TXG2746
CT5346BVC/SEM CT5399BVC/MABY CT566BW/SEP TXG2548 TXH2756 CT7251VC/IRT
CT5377BVC/SEM CT5072BVC/RCL CT566BW/SEP CT6346VC/SEM CT6846VC/SEM CT7202BVC/MABY
CT5377BVC/SAM CT566BV/GE TXH2555 CT6846VC/GE CT7202BVC/SEM
CT5372BVC/SEP CT566BW/SEM TXH2556 CT6846VC/SEP CT766W/SEM
CN5372 CT6346VC/GE TXH2869
CT6346VC/SEP TXH2879
CT7202WBC/SEM
1 PCB-ASSY AT MAIN SUB ASSY
2 CN501B DIRECT(AA39-20053A) L-CON(AA39-20020J)
3 CN502B DIRECT(AA39-20053A) L-CON(AA39-20029K)
4 CN501B DIRECT POSTHEADER(3711-001011)
5 CN502B DIRECT POSTHEADER(3711-001097)
6 R511 1/2W 61.9K(2004-001-899) 1/2W 100K(2004-001373) 1/2W 110K(2004-002011)
7 R512 1/2W 61.9K(2004-001-899) 1/2W 100K(2004-001373) 1/2W 110K(2004-002011)
8 R513 1/2W 61.9K(2004-001-899) 1/2W 100K(2004-001373) 1/2W 110K(2004-002011)
9 R525 RF 2W 1.5(2008-000257) RF 2W 0.18(2008-001011) RF 2W 3.9(2008-001049) RF 2W 1(2008-000266)
10 J512 NOT USED JUMPER(3812-000219) DELETE JUMPER(3812-000219) DELETE
11 J513 NOT USED JUMPER(3812-000220) DELETE JUMPER(3812-000219) DELETE
12 CRT-SOCKET DHE-A93-700(3704-000109) DHE-A90-700(3704-000111)
13 C504 C-C 15P(2202-000162) C-C 5.6P(2202-002005)
14 C505 C-C 15P(2202-000162) C-C 5.6P(2202-002005)
15 C506 C-C 15P(2202-000162) C-C 5.6P(2202-002005)
16 Q501 DELETE C815Y(0501-000389)
17 C520 DELETE 50V 104 P(2306-000122)
18 D505 DELETE 1N4148(0401-000005)
19 D506 DELETE 1N4148(0401-000005)
20 D507 DELETE 1N4148(0401-000005)
21 C501 63V 474(2305-000412) DELETE
22 R503 1/4W 10.5K(2004-000187) 1/2W 6.8K(2004-001402)
NO. LOC. NO. 19-INCH/20-INCH/21-INCH 25-INCH 23-INCH 27-INCH/28-INCH
6-3 CRT PCB PART (TDA6101Q IC)
