Samsung CT566BVX/STR - Page 35

Electric Parts List
Samsung Electronics 6-7
88 RX02 1/8W 62K(2004-001990) 1/8W 62K(2004-001990) 1/8W 62K(2004-001990) 1/8W 62K(2004-001990) 1/8W 62K(2004-001990) 1/8W 62K(2004-001990)
89 DY-CONN. DELETE DELETE DELETE NEW DELETE DELETE
90 J414 1/2 0.39(2001-003019) 1/2 0.39(2001-003019) JUMPER (3812-000219) JUMPER (3812-000219) JUMPER (3812-000219) JUMPER (3812-000219)
91 R419 RF 1/2W 0.47(2008-000252) RF 1/2W 0.47(2008-000252) RF 2W 1.5(2008-000257) RF 2W 0.68(2008-000254) RF 2W 1.2 RF 2W 1.2
92 L204 10 Uh(2701-000114) 10 Uh(2701-000114) 10 Uh(2701-000114) 10 Uh(2701-000114) 10 Uh(2701-000114) 10 Uh(2701-000114)
93 J413(R420)JUMPER (3812-000219) JUMPER (3812-000219) JUMPER (3812-000219) RF 1/2W 0.47 AX(2008-000252) RF 1/2W 0.47 AX(2008-000252) RF 1/2W 0.47 AX(2008-000252)
94 C208 DELETE DELETE DELETE DELETE P 50V 103(2301-000380) P 50V 103(2301-000380)
95 L402(03 lot)DELETE DELETE BEAD AXIAL(3301-000287) BEAD AXIAL(3301-000287) DELETE DELETE
96 J417 JUMPER (3812-000219) JUMPER (3812-000219) DELETE DELETE JUMPER (3812-000219) JUMPER (3812-000219)
97 J418 JUMPER (3812-000219) JUMPER (3812-000219) DELETE DELETE JUMPER (3812-000219) JUMPER (3812-000219)
98 C244 50V 2.2 UF(2401-000660) 50V 2.2 UF(2401-000660) 50V 4.7 UF(2401-001271) 50V 4.7 UF(2401-001271) 50V 2.2 UF(2401-000660) 50V 2.2 UF(2401-000660)
99 C405 P 250V 224(2301-000213) P 250V 224(2301-000213) P 250V 104(2305-000704) P 250V 104(2305-000704) P 250V 224(2301-000213) P 250V 224(2301-000213)
100 R415 2W 4.7K(2003-002007) 2W 4.7K(2003-002007) 1W 3.9K(2003-000993) 1W 3.9K(2003-000993) 2W 4.7K(2003-002007) 2W 4.7K(2003-002007)
101 L203 JUMPER (3812-000219) JUMPER (3812-000219) BEAD AXIAL(3301-000287) BEAD AXIAL(3301-000287) BEAD AXIAL(3301-000287) BEAD AXIAL(3301-000287)
NO. LOC. NO. 21Q (AC120V ) 21Q (FREE VOLT) 25-INCH 1R(AC 120V) 27-INCH 1R(AC 120V) 28-INCH Q(AC 120V) 1.5R 28-INCH Q(FREE VOLT)
6-2 Part Description (P/D) According to Screen Size (CONTINUED)
