Electric Parts List
6-10 Samsung Electronics
1 C209 DELETE (P)474(2305-000411) (P)474(2305-000411) Y-IN
2 R241 DELETE 820K(2004-001284) 820K(2004-001284) Y-IN
3 R242 DELETE 430K(2001-000755) 430K(2001-000755) Y-IN
4 R243 DELETE 1M(2001-000435) 1M(2001-000435) Y-IN
5 C206 DELETE (P)102(2301-000192) (P)102(2301-000192) C-IN
6 JF01 DELETE JUMPER (3812-000219) DELETE COMB-C
7 JF02 DELETE JUMPER (3812-000219) JUMPER (3812-000219)
8 JF03 DELETE JUMPER (3812-000219) DELETE COMB-Y
9 JF04 DELETE JUMPER (3812-000219) JUMPER (3812-000219)
10 J713 JUMPER (3812-000219) JUMPER (3812-000219) DELETE
11 CF01 DELETE UGL-352KNT(AA29-10002A) UGL-352KNT(AA29-10002A) COMB FILTER
12 JC01 JUMPER (3812-000219) JUMPER (3812-000219) DELETE CAPTION LINE
13 R819 2W 27 AF(2003-001035) 2W 22 AF(2003-000592) 2W 22 AF(2003-000592) B+ SETTING
STEREO REMARK
NO. LOC. NO. COMB COMB S-VHS
6-4 COMB FILTER OPTION
1 JE01 DELETE DELETE DELETE JUMPER
2 JE02 DELETE DELETE DELETE JUMPER
3 R701 DELETE DELETE 1/2W 100K(2001-000085) 1/2W 100K(2001-000085)
4 R702 DELETE DELETE 1/2W 100K(2001-000085) 1/2W 100K(2001-000085)
5 C628 DELETE DELETE 50V 10uF(2401-000480) 50V 10uF(2401-000480)
6 C632 DELETE DELETE 50V 10uF(2401-000480) 50V 10uF(2401-000480)
7 R619 DELETE DELETE 100(2001-000281) 100(2001-000281)
8 R624 DELETE DELETE 100(2001-000281) 100(2001-000281)
9 JV01 DELETE DELETE JUMPER (3812-000219) DELETE
10 JMV02 DELETE DELETE JUMPER (3812-000219) DELETE
11 JA701 2P(3722-001192) 3P(3722-001104) 5P(3722-001103) 6P(3722-001215)
NO. LOC. NO. NO OUT(MONO) NO OUT(ST) VAO MONITOR OUT
6-5 AUDIO OUT OPTION
