Samsung CT566BVX/STR - Page 48

C809 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5mm
C810 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11mm,5mm
C811 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C812 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C813 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C814 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
C815 2401-000293 C-AL;100uF,+30-10%,200V,HR,TP,16x25
C816 2401-000166 C-AL;1000uF,20%,25V,WT,TP,13x20mm,5
C817 2306-000323 C-FILM,MPPF;2.2nF,5%,1.6KV,TP,28.5x15.5x8.
C818 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
C820 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm
C821 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C823 2201-002002 C-CERAMIC,DISC;4700pF,20%,400V,+20%~-55%,TP,2
C825 2201-000292 C-CERAMIC,DISC;1nF,10%,50V,Y5P,TP,5x4,5mm
C826 2201-000556 C-CERAMIC,DISC;470pF,10%,500V,Y5P,TP,7x4,5
C850 2401-000808 C-AL;220uF,20%,16V,GP,TP,8x11mm,5mm
C851 2401-002289 C-AL;470uF,20%,35V,WT,TP,10x20,5
C852 2401-001415 C-AL;470uF,20%,35V,GP,TP,10x20mm,5m
C853 2401-000395 C-AL;10uF,20%,160V,GP,TP,10x12.5mm,
C861 2401-000242 C-AL;100uF,20%,10V,GP,TP,6x11,5mm
C862 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C901 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C902 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
C903 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C904 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
C905 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C906 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP,1.9x3.5,-
C907 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C908 2201-000573 C-CERAMIC,DISC;47pF,5%,50V,CH,TP,6.5x3.0,5
C909 2201-000193 C-CERAMIC,DISC;10pF,0.3pF,50V,CH,TP,5x3,5
C910 2201-000119 C-CERAMIC,DISC;100nF,+80-20%,50V,Y5V,TP,8x3.5
C911 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5mm
C912 2301-000380 C-FILM,PEF;10nF,5%,50V,TP,6.5x3mm,5mm
C913 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V,TP,-,7.5
C914 2202-000279 C-CERAMIC,MLC-AXIAL;47pF,5%,50V,SL,TP,3.5x19,-
C926 2202-000199 C-CERAMIC,MLC-AXIAL;22nF,+80-20%,25V,Y5V,TP,-,7.5
CB19 2301-001171 C-FILM,PPF;10nF,5%,400V,TP,20x6.5x13,7.5
CD01 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
CD02 2306-000122 C-FILM,MPPF;100nF,5%,50V,TP,7.3x4.0x5.0mm,
CD03 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
CD04 2401-001496 C-AL;47uF,20%,16V,GP,TP,5x7mm,5mm
CD05 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11mm,5mm
CD06 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm
CD13 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5mm
CD27 2306-000122 C-FILM,MPPF;100nF,5%,50V,TP,7.3x4.0x5.0mm,
CE01 2301-000380 C-FILM,PEF;10nF,5%,50V,TP,6.5x3mm,5mm
CE03 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20mm,5m
CLAMP/F AA65-30002ACLAMP-FBT;NYLON-66,V0,BLK,-,-,-
CLAMP/F AA65-30009ACLAMP-FBT;ABS,V0,BLK,-,-,-
CN501B AA39-20051BLEAD-CONNECTOR,ASSY;-,YBNH025-04,S,4P,400,1007#26
CN502B AA39-20053ALEAD-CONNECTOR,ASSY;-,YBNH025-05,S,5P,400,1007#26
CN601 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGHT,-
CN701 3711-002648 CONNECTOR-HEADER;BOX,9P,1R,2.5mm,STRAIGHT,-
CN905 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGHT,SN
CU02 2202-000109 C-CERAMIC,MLC-AXIAL;100nF,+80-20%,50V,Y5P,TP,1.9x3
CU06 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5.0mm
CU11 2202-000109 C-CERAMIC,MLC-AXIAL;100nF,+80-20%,50V,Y5P,TP,1.9x3
CU12 2202-000109 C-CERAMIC,MLC-AXIAL;100nF,+80-20%,50V,Y5P,TP,1.9x3
CU13 2202-000109 C-CERAMIC,MLC-AXIAL;100nF,+80-20%,50V,Y5P,TP,1.9x3
CUD01 2301-000285 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5mm
CUD02 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
CUD03 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
CUD04 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CUD05 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm
CUD06 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
CUD07 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
CUD08 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
CUD09 2301-000175 C-FILM,PEF;15nF,5%,50V,TP,7.1x3.5x13mm,5m
CUD10 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
CUD11 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
CUD12 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
CUD13 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
CUD14 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11mm,5mm
CX01 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
D-COIL AA27-20003T COIL-DEGAUSSING;-,22,16.7ohm,60T,2600mm,E
DIODE 0403-000704 DIODE-ZENER;TZP7.5B,7.5V,7.5-8.4V,1W,DO-41
D201 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D202 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D203 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D204 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D205 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D206 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D207 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D208 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D210 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D301 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D302 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D401 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L,TP
D402 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D403 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D404 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-
D405 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D503 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D511 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D512 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D513 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D602 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D801 0402-001018 DIODE-BRIDGE;RBV606,600V,6A,SIP-4
D803 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L,TP
D804 0402-000213 DIODE-RECTIFIER;ERB12-06,600V,1.0A,DO-41
D805 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D806 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D808 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D810 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L,TP
D811 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-
D814 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D815 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D818 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D819 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
D903 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D908 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D910 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
D951 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D962 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
DB02 0402-001012 DIODE-RECTIFIER;FMP-3FU,1500V,5A,TO-3PF
DU01 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
DU02 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
DU03 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,TP
Electric Parts List
6-20 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
!
!
!
!
!
