DX01 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41
DZ101 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,TP
DZ302 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,TP
DZ303 0403-000704 DIODE-ZENER;TZP7.5B,7.5V,7.5-8.4V,1W,DO-41
DZ305 0403-000660 DIODE-ZENER;MTZ22A,22V,20.15-21.2V,500mW,D
DZ306 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,TP
DZ401 0403-000300 DIODE-ZENER;MTZ8.2B,7.78-8.19V,500mW,DO-34
DZ402 0403-000295 DIODE-ZENER;MTZ5.1B,5.1V,4.94-5.20V,500mW,
DZ601 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ650 0403-000656 DIODE-ZENER;MTZ15C,15V,14.35-15.09V,500mW,
DZ651 0403-000656 DIODE-ZENER;MTZ15C,15V,14.35-15.09V,500mW,
DZ701 0403-000563 DIODE-ZENER;MTZ9.1B,9.1V,8.57-9.01V,500mW,
DZ702 0403-000563 DIODE-ZENER;MTZ9.1B,9.1V,8.57-9.01V,500mW,
DZ704 0403-000563 DIODE-ZENER;MTZ9.1B,9.1V,8.57-9.01V,500mW,
DZ801 1405-000188 VARISTOR;430V,1250A,14x7.5mm,TP
DZ802 1405-000188 VARISTOR;430V,1250A,14x7.5mm,TP
DZ804 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ805 0403-000563 DIODE-ZENER;MTZ9.1B,9.1V,8.57-9.01V,500mW,
DZ807 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ808 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ815 0403-000656 DIODE-ZENER;MTZ15C,15V,14.35-15.09V,500mW,
DZ901 0403-000295 DIODE-ZENER;MTZ5.1B,5.1V,4.94-5.20V,500mW,
DZ902 0403-000562 DIODE-ZENER;MTZ7.5B,7.5V,7.07-7.45V,500mW,
DZ903 0403-000297 DIODE-ZENER;MTZ6.2B,6.2V,5.96-6.27V,500mW,
DZ905 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ906 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ907 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ908 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500mW,
DZ910 0403-000297 DIODE-ZENER;MTZ6.2B,6.2V,5.96-6.27V,500mW,
DZE01 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,TP
DZX01 0403-000667 DIODE-ZENER;MTZ6.8A,6.8V,6.29-6.63V,500mW,
F801 3601-001012 FUSE-FERRULE;250V,4A,SLOW-BLOW,GLASS,5.2x20
F801A 3602-000114 FUSE-HOLDER;-,-,30mohm
F801B 3602-000114 FUSE-HOLDER;-,-,30mohm
GT102A AA39-20010BLEAD-CONNECTOR,ASSY;-,YFH800-01,S,1P,500,1617#22
IC201 1204-001170 IC-HOR./VER.PROCESSO;TDA8377A,DIP,56P,-,PLASTIC,8V,
IC202 1204-000506 IC-IF DETECTOR;LA7510,SIP,9P,-,PLASTIC,12V,-,
IC301 1204-000426 IC-VERTICAL PROCESSO;TDA8350Q/N4,SIP,13P,-,PLASTIC,
IC501 1201-001159 IC-VIDEO AMP;6107,ZIP,9P,300MIL,SINGLE,-,PL
IC602 1204-000395 IC-VOLUME CONTROL;UPC1406HA,SIP,9P,-,PLASTIC,15V
IC603 1201-000537 IC-AUDIO AMP;7057,ZIP,13P,-,DUAL,40dB,PLAST
IC701 0801-000961 IC-CMOS LOGIC;4053B,MUTIPLEXER,DIP,16P,300MI
IC801 AA13-20004VIC-HYBRID;-,STR-S5707,SIP,9P,SMPS CONTRO
IC802 1203-000644 IC-POSI.FIXED REG.;7630,SIP,10P,-,PLASTIC,5.1/8V,
IC853 1203-000165 IC-POSI.ADJUST REG.;78R12,TO-220,3P,-,-,12V,-,0to+
IC901 AA13-30002GIC-MCU;-,Z8933112PSC-R1789,16bit,SDIP
IC902 1103-000128 IC-EEPROM;24C02,256*8BIT,DIP,8P,300MIL,1
ICD01 1204-001204 IC-DECODER;TDA9850,DIP,32P,4000MIL,PLASTI
J414 2001-003019 R-CARBON(S);0.39ohm,10%,1/2W,AA,TP,2.4x6.4
JA701 3722-001104 JACK-RCA;3P(9P),3.4mm,AG,BLK,#16-22
L102 2701-000326 INDUCTOR-AXIAL;560nH,10%,2.3x3.4mm
L103 2701-000207 INDUCTOR-AXIAL;56uH,5%,2.5x3.4mm
L104 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L201 2701-000299 INDUCTOR-AXIAL;13uH,10%,2.5x3.4mm
L202 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,2400G
L204 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L205 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L206 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L301 2701-000116 INDUCTOR-AXIAL;10uH,10%,4.2x9.8mm
L401 AA27-30003L COIL-LINERITY;-,73uH,DR12x15,0.55mm,-,BK,15%
L403 AA27-10001DCOIL-CHOKE;-,6.8mH,K,50,150mA,ST,6.8MH-K(
L404 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,2400G
L405 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L406 2901-000296 FILTER-EMI ON BOARD;-,4.4/4.4mH,-
L602 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,2400G
L802 AA29-30002F FILTER-LINE NOISE;-,6mH,2.45A,-,-
L804 2901-000296 FILTER-EMI ON BOARD;-,4.4/4.4mH,-
L807 2901-000296 FILTER-EMI ON BOARD;-,4.4/4.4mH,-
L808 2901-000296 FILTER-EMI ON BOARD;-,4.4/4.4mH,-
L809 AA27-10002YCOIL-CHOKE;-,100uH,K,10,700mA,T,100UH-K(S
L810 AA27-10002YCOIL-CHOKE;-,100uH,K,10,700mA,T,100UH-K(S
L811 2901-000296 FILTER-EMI ON BOARD;-,4.4/4.4mH,-
L812 2901-000296 FILTER-EMI ON BOARD;-,4.4/4.4mH,-
L813 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5,TP,-
L862 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,2400G
L863 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,2400G
L864 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,2400G
L901 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L902 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
LA01 AA27-10002XCOIL-CHOKE;-,43uH,K,10,1A,T,43UH-K(SPT050
LD302 AA27-10001ECOIL-CHOKE;-,1.0uH,K,25,2100A,T,SP0408-1R
LD303 AA27-10001ECOIL-CHOKE;-,1.0uH,K,25,2100A,T,SP0408-1R
LD901 AA96-30001BASSY-LED,GUIDE;-,AA61-50055A,DL-G5RGA,-
LE01 AA27-40001F COIL-HORIZ.WIDTH;-,1mH,DR1520,PI0.4,-
NT801 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,TP
P801 1404-001087 THERMISTOR-PTC;7ohm,30%,220V,270V,19A,-,ST
Q101 0501-000436 TR-SMALL SIGNAL;KTC3197,NPN,625mW,TO-92,TP,20-
Q201 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,TP,120-
Q204 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,TP,120-
Q401 0502-000450 TR-POWER;2SD1887YD,NPN,1500V,800V,10A,7
Q402 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,-,120-
Q601 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,TP,120-
Q602 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,TP,120-
Q603 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,TP,120-
Q604 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,TP,120-
Q605 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,TP,120-
Q701 0504-000123 TR-DIGITAL;KSR1010,NPN,300mW,10K,TO-92,TP
Q702 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,TP,120-
Q901 0504-000123 TR-DIGITAL;KSR1010,NPN,300mW,10K,TO-92,TP
Q902 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,TP,120-
Q951 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,-,120-
QE01 0502-000242 TR-POWER;KSA614,PNP,25W,TO-220,TP,40-24
QU03 0504-000123 TR-DIGITAL;KSR1010,NPN,300mW,10K,TO-92,TP
QU05 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,TP,120-
QX01 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,TP,120-
R102 2001-000221 R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R103 2001-000539 R-CARBON;24Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R104 2001-000878 R-CARBON;6.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R107 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R108 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R109 2001-000117 R-CARBON(S);68ohm,5%,1/2W,AA,TP,2.4x6.4mm
R111 2001-000793 R-CARBON;47ohm,5%,1/8W,AA,TP,1.8x3.2mm
R112 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R113 2001-000577 R-CARBON;2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R114 2001-000221 R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R120 2001-000362 R-CARBON;150ohm,5%,1/8W,AA,TP,1.8x3.2mm
R202 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
R203 2001-000577 R-CARBON;2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
Electric Parts List
Samsung Electronics 6-21
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
To Next Page
