Samsung CT566BVX/STR - Page 33

Electric Parts List
Samsung Electronics 6-5
6-2 Part Description (P/D) According to Screen Size (CONTINUED)
26 CE01 50V 103 P (2301-000380) 50V 103 P (2301-000380) 50V 103 P (2301-000380) 50V 103 P (2301-000380) 50V 103 P (2301-000380) 50V 103 P (2301-000380)
27 CE03 250V 22(2401-000927) 250V 22(2401-000927) P 100V 0.47(2301-000271) P 100V 0.47(2301-000271) P 100V 0.47(2301-000271) P 100V 0.47(2301-000271)
28 DZE01 MA2560(0403-001039) MA2560(0403-001039) MA2560(0403-001039) MA2560(0403-001039) MA2560(0403-001039) MA2560(0403-001039)
29 J412 DELETE DELETE JUMPER(3812-000219) JUMPER(3812-000219) DELETE DELETE
30 LB02 DELETE DELETE DELETE DELETE 1.5 MH (AA27-40001E) 1.5 MH (AA27-40001E)
31 LE01 1 MH (AA27-40001F) 1 MH (AA27-40001F) DELETE DELETE 3 MH(AA27-40003J) 3 MH(AA27-40003J)
32 QE01 A614-Y (0502-000242) A614-Y (0502-000242) DELETE DELETE A614-Y (0502-000242) A614-Y (0502-000242)
33 QE01*-H/S AA62-30153C AA62-30153C DELETE DELETE AA62-30153C AA62-30153C
34 RE01 1/2W 5.6K (2001-001155) 1/2W 5.6K (2001-001155) JUMPER(3812-000219) JUMPER(3812-000219) 1/2W 5.6K (2001-001155) 1/2W 5.6K (2001-001155)
35 RE02 1/2W 43K(2001-001149) 1/2W 43K(2001-001149) JUMPER(3812-000219) JUMPER(3812-000219) 1/2W 43K(2001-001149) 1/2W 43K(2001-001149)
36 RE03 1/2W 100 (2001-000028) 1/2W 100 (2001-000028) 1/2W 100 (2001-000028) 1/2W 100 (2001-000028) 1/2W 100 (2001-000028) 1/2W 100 (2001-000028)
37 RE05 RF 2W 0.47(2008-001018) RF 2W 0.47(2008-001018) DELETE DELETE RF 2W 0.47(2008-001018) RF 2W 0.47(2008-001018)
38 RE07 RF 2W 0.47(2008-001018) RF 2W 0.47(2008-001018) DELETE DELETE RF 2W 0.47(2008-001018) RF 2W 0.47(2008-001018)
39 R211 1/8W 39K (2001-000702) 1/8W 39K (2001-000702) 1/8W 200K (2001-000004) 1/8W 180K (2001-000397) 39K(2001-000702) 39K(2001-000702)
40 R217 1/8W 51K (2001-000837) 1/8W 51K (2001-000837) 1/8W 220K (2001-000508) 1/8W 220K (2001-000508) 82K(2004-001301) 82K(2004-001301)
41 R219 1/8W 22K(2001-000522) 1/8W 22K(2001-000522) 1/2W 470K (2001-001150) 1/2W 270K (2001-001113) 1/2W 22K(2001-000522) 1/2W 22K(2001-000522)
42 R411 1/2W 100K-F(2004-001373) 1/2W 100K-F(2004-001373) 1/2W 91K-F(2004-001408) 1/2W 61.9K-F(2004-001899) 1/2W 51K F(2004-002022) 1/2W 51K F(2004-002022)
43 R412 1/2W 100K-F(2004-001373) 1/2W 100K-F(2004-001373) 1/2W 82K(2001-001194) 1/2W 82K(2001-001194) 1/2W 68K F(2004-001967) 1/2W 68K F(2004-001967)
44 C303 100V 104P(2305-000149) 100V 104P(2305-000149) 100V 103P(2305-000178) 100V 103P(2305-000178) 100V 104P(2305-000149) 100V 104P(2305-000149)
45 DZ306 TZP33A(0403-000700) TZP33A(0403-000700) TZP33A(0403-000700) TZP33A(0403-000700) TZP33A(0403-000700) TZP33A(0403-000700)
46 IC301 TDA8350Q(1204-000426) TDA8350Q(1204-000426) TDA8350Q(1204-000426) TDA8350Q(1204-000426) TDA8350Q(1204-000426) TDA8350Q(1204-000426)
47 LD302 1 uH(AA27-10001E) 1 uH(AA27-10001E) DELETE DELETE 1 uH(AA27-10001E) 1 uH(AA27-10001E)
48 LD303 1 uH(AA27-10001E) 1 uH(AA27-10001E) DELETE DELETE 1 uH(AA27-10001E) 1 uH(AA27-10001E)
49 LE304 DELETE DELETE 1 uH(AA27-10001E) 1 uH(AA27-10001E) DELETE DELETE
50 LE305 DELETE DELETE 1 uH(AA27-10001E) 1 uH(AA27-10001E) DELETE DELETE
51 R301 1/8W 1.3K(2001-000232) 1/8W 1.3K(2001-000232) 1/8W 2K (2001-000577) 1/8W 2.4K (2001-000006) 1/8W 2.4K (2001-000006) 1/8W 2.4K (2001-000006)
52 R303 DEELETE DEELETE DELETE DEELETE DEELETE DEELETE
53 R307 1/2W 1(2001-000016) 1/2W 1(2001-000016) 1/2W 1(2001-000016) 1/2W 1(2001-000016) 1/2W 1(2001-000016) 1/2W 1(2001-000016)
54 R308 1/2W 1(2001-000016) 1/2W 1(2001-000016) 1/2W 1(2001-000016) 1/2W 1(2001-000016) 1/2W 1(2001-000016) 1/2W 1(2001-000016)
55 R306 RS 2W 300(2003-000998) RS 2W 300(2003-000998) RS 2W 300(2003-000998) RS 2W 270(2003-002037) AF 2W 470(2003-002069) AF 2W 470(2003-002069)
56 R309 RS 2W 300(2003-000998) RS 2W 300(2003-000998) RS 2W 300(2003-000998) RS 2W 270(2003-002037) AF 2W 470(2003-002069) AF 2W 470(2003-002069)
NO. LOC. NO. 21Q (AC120V ) 21Q (FREE VOLT) 25-INCH 1R(AC 120V) 27-INCH 1R(AC 120V) 28-INCH Q(AC 120V) 1.5R 28-INCH Q(FREE VOLT)
