Electric Parts List
Samsung Electronics 6-13
73 JM06 DELETE JUMPER (3812-000219) AV SW,JACK PART
74 JM07 DELETE p 63v 224(2305-000289) MTS PART
75 JM07 DELETE JUMPER (3812-000219) MTS PART
76 JMC2 DELETE JUMPER (3812-000219) 1 CHIP PART
77 JMV02 DELETE JUMPER (3812-000219) MTS PART
78 JUD01 JUMPER (3812-000219) DELETE MTS PART
79 JUD02 JUMPER (3812-000219) DELETE MTS PART
80 JUD03 JUMPER (3812-000219) DELETE MTS PART
81 JUD04 JUMPER (3812-000219) DELETE MTS PART
82 JUD07 JUD07 DELETE MTS PART
83 JUD09 JUMPER (3812-000219) DELETE MTS PART
84 JV01 DELETE JUMPER (3812-000219) AV SW,JACK PART
85 Q602 A539Y(0501-000283) DELETE CONTROL IC PART
86 Q701 KSR1010(0504-000123) DELETE AV SW,JACK PART
87 Q702 C815Y(0501-000389) DELETE AV SW,JACK PART
88 R245 DELETE 1/8W 100 K(2001-000273) 1 CHIP PART
89 R606 1/8W 2.2K(2001-000449) 1/8W 15 K(2001-000008) MTS PART
90 R610 1/2W 47(2001-001153) DELETE CONTROL IC PART
91 R611 1/8W 100 K(2001-000273) DELETE CONTROL IC PART
92 R614 1/8W 10 K(2001-000290) DELETE CONTROL IC PART
93 R616 1/8W 4.7K(2001-000734) DELETE CONTROL IC PART
94 R620 1/8W 100(2001-000281) DELETE CONTROL IC PART
95 R621 1/8W 100(2001-000281) DELETE CONTROL IC PART
96 R703 1/8W 100(2001-000281) DELETE AV SW,JACK PART
97 R705 1/8W 10 K(2001-000290) DELETE AV SW,JACK PART
98 R707 1/8W 150(2001-000362) DELETE AV SW,JACK PART
99 R708 1/2W 100K(2001-000085) DELETE AV SW,JACK PART
100 R709 1/2W 4.7(2001-001146) JUMPER (3812-000219) CONTROL IC PART
101 R710 1/8W 150(2001-000362) DELETE AV SW,JACK PART
102 R716 1/8W 10 K(2001-000290) DELETE AV SW,JACK PART
103 R717 1/8W 10 K(2001-000290) DELETE AV SW,JACK PART
104 R953 1/8W 10 K(2001-000290) DELETE CONTROL IC PART
105 R954 1/8W 10 K(2001-000290) DELETE CONTROL IC PART
106 RD01 1/8W 2.2K(2001-000449) DELETE MTS PART
107 RD21 1/8W 100(2001-000281) DELETE MTS PART
108 RD22 1/8W 100(2001-000281) DELETE MTS PART
109 RU21 1/8W 1 K(2001-000429) DELETE MTS PART
110 RU22 1/8W 1 K(2001-000429) DELETE MTS PART
111 RUD01 1/8W 8.2K-G(2004-001256) DELETE MTS PART
112 RUD02 1/8W 160(2001-000384) DELETE MTS PART
113 RUD03 1/8W 7.5 K(2001-000947) DELETE MTS PART
114 RUD04 1/8W 7.5 K(2001-000947) DELETE MTS PART
115 ZU01 CSB503 F58(2802-001054) DELETE MTS PART
NO. LOC. NO. STEREO(CT566BW) MONO(CT566BV) REMARK
6-7 MONO STEREO OPTION (CONTINUED)
02 LOT
03 LOT
