Samsung CT566BVX/STR - Page 51

R827 2001-001088 R-CARBON(S);1Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R828 2001-001093 R-CARBON(S);2.2Kohm,5%,1/2W,AA,TP,2.4x6.4m
R832 2001-001187 R-CARBON(S);75ohm,5%,1/2W,AA,TP,2.4x6.4mm
R901 2001-000793 R-CARBON;47ohm,5%,1/8W,AA,TP,1.8x3.2mm
R902 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R903 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R904 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R906 2001-000472 R-CARBON;2.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R907 2004-001291 R-METAL;820ohm,5%,1/8W,AA,TP,1.8x3.2mm
R908 2001-000232 R-CARBON;1.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
R909 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R911 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R912 2001-000832 R-CARBON;510ohm,5%,1/8W,AA,TP,1.8x3.2mm
R914 2001-000490 R-CARBON;200ohm,5%,1/8W,AA,TP,1.8x3.2mm
R915 2001-000241 R-CARBON;1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
R920 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R921 2001-001062 R-CARBON(S);10Mohm,5%,1/2W,AA,TP,2.4x6.4mm
R922 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R923 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R924 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R925 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R926 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R927 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R928 2004-001234 R-METAL;75Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R930 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R931 2001-000397 R-CARBON;180Kohm,5%,1/8W,AA,TP,1.8x3.2m
R932 2001-001062 R-CARBON(S);10Mohm,5%,1/2W,AA,TP,2.4x6.4mm
R935 2001-000832 R-CARBON;510ohm,5%,1/8W,AA,TP,1.8x3.2mm
R951 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R952 2001-000472 R-CARBON;2.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R953 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R954 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R956 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R957 2001-000117 R-CARBON(S);68ohm,5%,1/2W,AA,TP,2.4x6.4mm
R958 2001-000241 R-CARBON;1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
R959 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R960 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R961 2001-000766 R-CARBON;43Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R962 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R964 2001-001088 R-CARBON(S);1Kohm,5%,1/2W,AA,TP,2.4x6.4mm
R965 2001-000273 R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m
RA01 2003-000458 R-METAL OXIDE(S);100ohm,5%,2W,AF,TP,4x12mm
RA02 2003-000458 R-METAL OXIDE(S);100ohm,5%,2W,AF,TP,4x12mm
RD01 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
RD21 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
RD22 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
RE01 2001-001155 R-CARBON(S);5.6Kohm,5%,1/2W,AA,TP,2.4x6.4m
RE02 2001-001149 R-CARBON(S);43Kohm,5%,1/2W,AA,TP,2.4x6.4mm
RE03 2001-000028 R-CARBON(S);100ohm,5%,1/2W,AA,TP,2.4x6.4mm
RE05 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10mm
RE07 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10mm
RH01 2001-000085 R-CARBON(S);100Kohm,5%,1/2W,AA,TP,2.4x6.4m
RL801 3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS,5m
RM901 AA59-60001UMODULE-REMOCON;-,ORC-50VF/SR-12V,38KHz,940nm,
RN01 2004-001291 R-METAL;820ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU02 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU03 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU04 2001-000577 R-CARBON;2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU05 2001-000577 R-CARBON;2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU06 2001-000577 R-CARBON;2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU07 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU08 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU09 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU10 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU12 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU13 2001-000613 R-CARBON;3.9Kohm,5%,1/8W,AA,TP,1.8x3.2m
RU14 2004-001989 R-METAL;620ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU15 2004-001989 R-METAL;620ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU16 2004-001989 R-METAL;620ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU17 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU18 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU19 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU20 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU21 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RU22 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RUD01 2004-001256 R-METAL;8.2Kohm,2%,1/8W,AA,TP,1.8x3.5m
RUD02 2001-000384 R-CARBON;160ohm,5%,1/8W,AA,TP,1.8x3.2mm
RUD03 2001-000947 R-CARBON;7.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
RUD04 2001-000947 R-CARBON;7.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
RX01 2001-000397 R-CARBON;180Kohm,5%,1/8W,AA,TP,1.8x3.2m
RX02 2004-001990 R-METAL;62Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RX03 2001-000522 R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RX04 2001-000766 R-CARBON;43Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RX05 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RX06 2008-000206 R-FUSIBLE(S);1ohm,5%,1/2W,AF,TP,2.5x6.5mm
SF101 2904-000287 FILTER-SAW AV;45.75MHz,SIP5P,ST,12.5dB,NTSC-
SF102 2904-000289 FILTER-SAW AV;45.75MHz,SIP5P,ST,14.4dB,NTSC-
SW901 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SPST
SW902 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SPST
SW903 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SPST
SW904 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SPST
SW905 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SPST
SWN01 3404-001004 SWITCH-TACT;12V,50mA,160gf,8.4x22.7mm,SPST
T201 AA26-10005E TRANS-IF;-,7MM,IF,0.136uH,7mm,27pF,81.5
T403 AA26-50001BHORIZ.DRIVE;-,7.1mH,102uH,10-20uH,YL081,ST
T444 AA26-30005E TRANS-FLYBACK;-,FTK-21B003(S),22,130V
T801 AA26-20007GTRANS-SWITCHING;-,90VAC~260VAC,130/15/15,KS,EE
TU01 AA40-10005T TUNER-F/S;TECC1070PG26A(S),NTSC/USA,TR,1
V999 3704-000109 SOCKET-CRT;14P,29.1,22.5,SN,DHE-A93-700MS
WIRE3 AA65-30104BCLAMP-WIRE;NYLON 66N,V0,BLK,W2 Z5,ALL MOD
X202 2801-000229 CRYSTAL-UNIT;3.579545MHz,30ppm,28-AAM,S,75o
X901 2801-003224 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5pF,
Z201 2903-000129 FILTER-CERAMIC;TR,4.5M/4.72MHZ,-,-,-,TP,-
Z601 2903-000134 FILTER-CERAMIC;BP,4.5MHz,+-60KHz,6dB,-,TP,-
ZU01 2802-001054 RESONATOR-CERAMIC;514.5KHz,1.5KHz,BK,7.0x3.5x9mm
ASSY-ACCESSORY
3721-000136 PLUG-CONVERSION;2P,4.0mm,N,NI
AA26-90001F TRANS-MATCHING;-,300ohm/75ohm,NTSC,40-890MHz
AA68-11175AMANUAL-USERS;KCT57,SPA,TM59,B5,W/P 100(G),-
AA68-11176AMANUAL-USERS;KCT57,ENG,TM59,B5,W/P 100(G),-
ASSY-CRT
AA03-10028ZCRT-COLOR;-,A53QCA891X(B),0mG,21,90deg,
AA27-50004NDEFLECTION-YOKE;-,DSQ-2192AL,21/A53QCA691X,SH
AA27-60001DMAGNET-CONVERGENCE;-,JH-291-(JH-8210),29.1mm
Electric Parts List
Samsung Electronics 6-23
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
!
!
!
!
!
!
!
!
!
!
!
!
!
