Samsung CT566BVX/STR - 2-3 Semiconductor Base Diagrams

2-3 Semiconductor Base Diagrams
Specifications and IC Data
Samsung Electronics 2-3
ELECTROLYTIC-
CONDENSER
IC
DIODE
XLS24C02P (PIN 8)
TDA8375 (PIN 56)
RM168E (PIN 42)
TDA9850 (PIN 22)
TDA4053 (PIN 16)
IC
TRANSISTOR TRANSISTOR
TDA8133
TDA8356
KA7812
KA7809
IN
G
out
C2331-Y
KSR1010
TRANSISTOR
TRANSISTOR
KSC2073
KSA940
2SD1887
2SD1880
KSD5072
B
C
E
E B C
KSC815Y
KSA539-Y
M3951M
M9260M
SAW-FILTER
1
E C B
Fig. 2-1 Semiconductor Base Diagrams
