Exploded views and Parts list _ 41
MODEL CODE: DV409SEL/XAC
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Drawing
No.
Code No. Description Specification QTY Un SA/SNA
0 ASSY-FRAME FRONT & DOOR 1
1 DC97-14563E ASSY DOOR NORMAN-DRYER(BEST),592-895090, 1 PC SA
1-1 DC97-14593D ASSY COVER DOOR NORMAN-DRYER(BEST),592-8 1 PC SA
1-1-1 DC64-01552B DOOR-SAFETY ACE-PJT,PET,T2.5,-,W514,L514 1 PC SA
1-1-2 DC64-01366G DECORATION-DOOR 592-895090,EGI,T0.5,IMPE 1 PC SNA
1-1-3 DC63-00885A COVER-DOOR PURPLE-PJT,ABS,T2.5,W541,L541 1 PC SNA
1-2 6002-000241 SCREW-TAPPING TH,+,-,2S,M5,L12,ZPC(WHT), 1 PC SA
1-3 6002-000444 SCREW-TAPPING TH,+,-,2S,M4,L14,PASS,STS4 12 PC SNA
1-4 6002-000445 SCREW-TAPPING TH,+,-,2S,M4,L18,PASS,STS4 2 PC SA
1-5 6002-001306 SCREW-TAPPING TH,+,-,1,M4,L14,ZPC(WHT),S 8 PC SNA
1-6 DC61-00891A GUIDE-HINGE HAUZEN(DOM),POM,-,-,-,WHT,HI 4 PC SA
1-7 DC61-01532B HINGE-DOOR WF328,ALDC,T3.8,-,-,GRY,-,SPR 1 PC SA
1-8 DC61-01576A SUPPORT-HINGE FRONTIER-PJT,SBHG1-A(SGCC) 1 PC SA
1-9 DC61-01991A HOLDER-GLASS PURPLE DRYER,PP(TB53),T2.8, 1 PC SA
1-10 DC62-00262A SEAL-DOOR DV448AEW,TPE,GRY,-,-,1280mm,PU 1 PC SA
1-11
DC64-00993A DOOR-GLASS WINGS-DRYER,GLASS,T5,-,-,-,TR 1 PC SA
1-12 DC66-00395A LEVER-DOOR WINGS-DRYER,POM,-,-,-,-,NTR,- 1 PC SA
2 DC97-15509D ASSY FRAME FRONT ACE-DRYER,DV409SEL,ANDR 1 PC SA
2-1 6001-001773 SCREW-MACHINE TH,+,-,M5,L12,PASS,STS430, 2 PC SA
2-2 6002-000231 SCREW-TAPPING TH,+,-,2S,M4,L12,ZPC(WHT), 2 PC SNA
2-3 6002-000239 SCREW-TAPPING TH,+,-,2S,M4,L8,ZPC(WHT),S 9 PC SA
2-4 DC61-01990C FRAME-FRONT DV428AEL,EGI,-,-,ANDRE-BLUE, 1 PC SA
2-5 DC97-07510B ASSY HOLDER LEVER -,MDE7800AYW,DRYER/DOO 1 PC SA
2-6 DC61-01222A BRACKET-HINGE 27-DRYER,HGI,T2.0,-,-,-,- 2 PC SA
2-7 DC63-10001C SPONGE-EPDM -,EPDM,-,T3.0,W15,L350,BLK,O 8 PC SNA
2-8 DC64-00828A DOOR-S/W GD-PJT,PA,T13.6,H38.5,W44.3,-,W 1 PC SA
2-9 DC64-01878C DECORATION-FRONT 592-895090,ABS,T2.5,W70 1 PC SA
