Exploded views and Parts list _ 43
MODEL CODE: DV409SEL/XAC
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Drawing
No.
Code No. Description Specification QTY Un SA/SNA
0 DC97-15654A ASSY PANEL CONTROL ACE-DRYER(BETTER),DV4 1 PC SNA
1 DC92-00256B ASSY PCB SUB ACE-PJT,DV409,-,120V/60Hz,- 1 PC SA
2 DC97-14447A ASSY KNOB ENCODER WF438AAW,-,-,-,- 1 PC SA
3 DC97-15711A ASSY S.PANEL CONTROL ACE-DRYER,DV409SEL/ 1 PC SA
3-1 DC64-01387A MASCOT FRONTIER II,NICKEL,-,-,-,-,-,- 1 PC SNA
3-2 DC64-01871A WINDOW-ENCODER WF419AAW/XAA,ACRYL(PMMA), 1 PC SNA
3-3 DC64-01873A DECORATION-ENCODER WF419AAW/XAA,ABS,T2.8 1 PC SNA
3-4 DC64-01879A PANEL-CONTROL DV409SEL,ABS,T3.0,ANDRE-BL 1 PC SNA
3-5 DC64-01979B WINDOW-PANEL DV409SEL,ABS,T1.0,W20.1,L13 1 PC SNA
3-6 DC64-01980A DECORATION-LED WF409SNL,PMMA,T1.2,W118.2 1 PC SNA
3-7 DC97-15666A ASSY BUTTON ACE,WF409SNL 1 PC SA
3-7-1 DC64-01845C BUTTON-PUSH(P) WF409SNL,ABS,ONYX BLUE,AC 1 PC SA
3-7-2 DC64-01975A BUTTON-RUBBER WF409SNL,SILICON,NTR,ACE-P 1 PC SNA
