English 31
06 Other Information
Specifications
General
Weight 2.04 Kg
Dimensions 430 (W) x 61 (H) x 230 (D) mm
Operating Temperature Range +5°C~+35°C
Operating Humidity Range 10 % to 75 %
FM Tuner
Signal/noise ratio 60 dB
Usable sensitivity 10 dB
Total harmonic distortion 1%
Disc
DVD (Digital Versatile Disc)
Reading Speed : 3.49 ~ 4.06 m/sec.
Approx. Play Time (Single Sided, Single Layer Disc) : 135 min.
CD : 12 cm (COMPACT DISC)
Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 74 min.
CD : 8cm (COMPACT DISC)
Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 20 min.
Video Output
Composite Video
480i(576i)
1 channel : 1.0 Vp-p (75 Ω load)
Component Video
480i(576i)
Y : 1.0 Vp-p (75 Ω load)
Pr : 0.70 Vp-p (75 Ω load)
Pb : 0.70 Vp-p (75 Ω load)
Amplifier
Front speaker output
35W x 2(3Ω)
Subwoofer output
80W(3Ω)
Frequency range
20Hz~20KHz
S/N Ratio
65dB
Channel separation
60dB
Input sensitivity
(AUX)800mV
Speaker
Speaker system
2.1ch speaker system
Impedance
Frequency range
Output sound pressure level
Rated input
Maximum input
Dimensions (W x H x D)
Weights
*: Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- Design and specifications are subject to change without prior notice.
- For the power supply and Power Consumption, refer to the label attached to the product.
Front: 0.3 Kg, Subwoofer : 2.89 Kg
Front : 77 x 107 x 68 mm
Subwoofer : 154 x 299 x 285 mm
Subwoofer
3 Ω
20Hz~160Hz
88dB/W/M
80W
160W
Front
3 Ω
140Hz~20KHz
86dB/W/M
35W
70W
