Connecting the FM Antenna
DIGITAL
AUDIO IN
OPTICAL
VIDEO
OUT
AUX
IN
LANiPod WIRELESS
HDMI IN
2
1
HDMI OUT
FRONT
SPEAKERS OUT
SUBWOOFER
CENTER FRONT
SURROUND
SURROUND
SPEAKER IMPEDANCE : 3
DIGITAL
AUDIO IN
OPTICAL
VIDEO
OUT
AUX
IN
LAN
iPod
WIRELESS
HDMI IN
2
1
HDMI OUT
FRONT
SPEAKERS OUT
SUBWOOFER
CENTER
FRONT
SURROUND
SURROUND
SPEAKER IMPEDANCE : 3
FM ANT
FM Antenna (supplied)
1 . Connect the FM antenna supplied to the FM ANTENNA Jack.
2 . Slowly move the antenna wire around until you find a location where reception is good, then fasten it
to a wall or other rigid surface.
|
NOTE |

This product does not receive AM broadcasts.
Connecting to an iPod/iPhone
Using a USB Cable
Connect an iPod/iPhone using the USB cable to
the front USB port.
Using a Dock
Composite cable must be connected to play a
video.
