68 English
Appendix
Speaker
Speaker system
5.1ch speaker system
Front Surround Centre Subwoofer
Impedance 3 Ω 3 Ω 3 Ω 3 Ω
Frequency range 140Hz~20kHz 140Hz~20kHz 140Hz~20kHz 40Hz ~ 160Hz
Output sound
pressure level
87dB/W/M 87dB/W/M 87dB/W/M 88dB/W/M
Rated input 165W 165W 170W 170W
Maximum input 330W 330W 340W 340W
Dimensions
(W x H x D)
Front : 94 x 280 x 70 mm
Surround : 90 x 141.5 x 68.5 mm
Centre : 360 x 74.5 x 68.5 mm
Subwoofer : 200 x 390 x 350 mm
Weights
Front : 0.95 kg, Surround : 0.61 kg
Centre : 0.9 kg, Subwoofer : 5.7 kg
• Network speeds equal to or below 10Mbps are not supported.
• Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
• Weight and dimensions are approximate.
• Design and specifications are subject to change without prior notice.
• For the power supply and Power Consumption, refer to the label attached to the product.
