Samsung MIM-E03CN - Indoor Zone and Connection Info

18
Installation/Service mode
English
Installation/Service mode
Step 1 Step 2 Step 3 Description Default
Indoor Zone
Option
Indoor Zone
Status
Information
Central : ON/OFF -
Normal Power : ON/OFF -
Mode : Heat/Cool/Auto -
DHW Power : ON/OFF -
DHW Mode :
Economic/Standard/
Power/Forced
-
Water Pump : ON/OFF -
BUH : ON/OFF -
BSH : ON/OFF -
Flow sensor : lpm -
Inverter Pump : 0% ~ 100% -
EEV Step : 0~2000Step -
Thermostat 1 : ON/OFF -
Thermostat 2 : ON/OFF -
DHW Thermostat : ON/OFF -
Connection
Information
Number of
Connection
0 to 16 -
View Master
Indoor Unit
Address -
Master Indoor
Zone Information
Serial No. : - -
Indoor Unit Eva In
Temp.(Teva_in) :
Temperature -
Indoor Unit Eva
Out Temp.(Teva_
out) :
Temperature -
Indoor Unit PHE
IN(Tw1) :
Temperature -
Indoor Unit PHE
OUT(Tw2) :
Temperature -
DHW Tank Temp.
(Tt) :
Temperature -
DHW Mode :
Economic/Standard/
Power/Forced
-
