Field setting mode
English
Field Setting Mode
DVM Hydro unit: Only AM****NBD*** Model
࡙ The values in the following table are just examples for your understanding.
Classification Function Detail
Code
(Main
+ sub
menu)
Basic Min. Max. Step Unit
Remote
controller
Temperature of general
cooling leaving water
Max. 1011 25 ߢߩ 25 1 °C
Min. 1012 16 5 ߢߩ 1°C
General indoor cooling
temperature
Max. 1021 30 ߣߩ 30 1 °C
Min. 1022 ߢߩ ߢߩ ߣߩ 1°C
Temperature of general
heating leaving water
Max. 1031 50 37 50 1 °C
Min. 1032 25 15 37 1 °C
General indoor heating
temperature
Max. 1041 30 ߢߩ 30 1 °C
Min. 1042 16 16 ߢߩ 1°C
Temperature of hot water
tank
Max. 1051 50 40 75 1 °C
Min. 1052 35 30 40 1 °C
Water Law
Auto heating ambient
temperature
Max. 2011 -10 -20 5 1 °C
Min. 2012 15 10 20 1 °C
Temperature of auto
heating leaving water
(WL1-Floor)
Max. 2021 45 35 50 1 °C
Min. 2022 30 17 37 1 °C
Temperature of auto
heating leaving water
(WL2-FCU)
Max. 2031 50 35 50 1 °C
Min. 2032 35 17 50 1 °C
Auto heating of wired
remote controller
WL type 2041 1 (WL1) 1 2 - -
Use of thermostat - 2091 0 (No) 0 2 - -
DHW
Activating hot water
function
DHW application 3011 0 (No) 0 1 (Yes) - -
Heating mode
Max. 3021 50 45 50 1 °C
Stop 3022 2 0 10 1 °C
Start 3023 5 5 20 1 °C
Minimum heating
operation time
3024 5 1 20 1 min.
DHW operation time 3025 30 5 95 5 min.
Heating operation time 3026 3 0.5 10 0.5 hour
Booster heater
Operation 3031 1 (On) 0 (Off) 1 - -
Delayed time 3032 20 20 95 5 min.
Overshoot 3033 0 0 4 1 °C
