47
Field Setting Mode
• Cooling mode (FSV #5082 = 2℃, Default)
– Room sensor setting: Current setting value - FSV #5082 (Min = FSV #1022)
– Water outlet setting: Current setting value - FSV #5082 (Min = FSV #1012)
– Water law setting: Current setting value - FSV #5082 (Min = FSV #2061, #2062, #2071, #2072)
• Heating mode (FSV #5083 = 2℃, Default)
– Room sensor setting: Current setting value + FSV #5083 (Max = FSV #1041)
– Water outlet setting: Current setting value + FSV #5083 (Max = FSV #1031)
– Water law setting: Current setting value + FSV #5083 (Max = FSV #2021, #2022, #2031, #2032)
• DHW mode
– Thermo on operation regardless of Away mode: Setting temperature = Max temperature of DHW mode
(FSV #1051)
Smart Grid Control (FSV#5091~5094)
The FSV #5091 should be set to "1(Yes)" for Smart grid control.
FSV 0 1
#5091 Disable (Default) Activation
[Operation mode for Smart grid]
Operation Mode Terminal 1 Terminal 2
Mode 1 Short Open
Mode 2 Open Open
Mode 3 Open Short
Mode 4 Short Short
• Mode 1 : Forced thermo off operation of all system
• Mode 2 : Normal operation
It is equally applied both heating and DHW mode.
•
The heating and DHW setting temperature are set by the FSV setting value.
– Heating mode (Room sensor setting) : Current setting value + FSV #5092
– Heating mode (Water outlet setting) : Current setting value + FSV #5092
– Heating mode (Water law setting) : Current setting value + FSV #5092
– DHW mode : Current setting value + FSV #5093
• Mode 4 : When operating on, the setting temperature is reflected as follows.
DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 47DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 47 2024-12-11 오전 10:04:432024-12-11 오전 10:04:43
