Samsung ML-1645

Service Manual
ExplodedView and Parts list
5-3
Samsung Electronics
Drawer# SEC_CODE DESCRIPTION QT’Y Service Grade Remark
5.1-0 ML-2240 SET
5.1-0 ML-1640 SET
5.1-1 JC96-05123A ELA UNIT-FRAME 1 SA A 2240
5.1-1 JC96-05120A ELA UNIT-FRAME 1 SA A 1640
5.1-2 JC97-03181A MEA-COVER MAIN 1 SA A 1640
5.1-2 JC97-03182E MEA-COVER MAIN 1 SA A 1645
5.1-2-1 JC61-01460D GUIDE-STACKER COVER 1 SNA B 1640
5.1-2-1 JC61-01460E GUIDE-STACKER COVER 1 SNA B 1645
5.1-2-2 JC63-01886A COVER-TOP 1 SA B 1640
5.1-2-2 JC63-01886M COVER-TOP 1 SA B 1645
5.1-2-3 JC63-01887A COVER-MAIN 1 SA B 1640
5.1-2-3 JC63-01887B COVER-MAIN 1 SA B 1645
5.1-2-4 JC63-01888A COVER-JAM 1 SA B 1640
5.1-2-4 JC63-01888B COVER-JAM 1 SA B 1645
5.1-2-5 JC72-01343A PMO-SUB_M_STACKER 2 SA D
5.1-2-6 JC64-00406A KEY-ONLINE 1 SNA D
5.1-2-7 6107-001169 SPRING-CS 1 SA B
5.1-2-8 JC67-00301A LENS-LED 1 SA B
5.1-2-9 JC66-02005A ACTUATOR-JAM 1 SNA B
5.1-2-10 JC61-00049A SPRING ETC-TR(KOR) 1 SNA B
5.1-3 JC97-03183A MEA UNIT-COVER FRONT 1 SA B 1645
5.1-3 JC97-03184A MEA UNIT-COVER FRONT 1 SA B 1640
5.1-3-1 JC63-01883A COVER-FRONT 1 SA B 1640
5.1-3-1 JC63-01883B COVER-FRONT 1 SA B 1645
5.1-3-2 JC63-01885A COVER-CASSETTE 1 SA B 1640
5.1-3-2 JC63-01885B COVER-CASSETTE 1 SA B 1645
5.1-3-3 JC63-01890A COVER-DUMMY CASSETTE 2 SA B 1640
5.1-3-3 JC63-01890B COVER-DUMMY CASSETTE 2 SA B 1645
5.1-3-4 JC63-00628F TRAY-EXTENSION LARGE 1 SA B
5.1-3-5 JC63-00629F TRAY-EXTENSION SMALL 1 SA B
5.1-4 JC96-04065A ELA UNIT-LSU 1 SA A
5.1-5 JC63-01892A COVER-SMPS 1 SA B 1640
5.1-5 JC63-01892B COVER-SMPS 1 SA B 1645
5.1-5-1 JC31-00092A FAN 1 SA A
5.1-6 JC96-05045A CARTRIDGE-TONER 1 SNA B 1640/2240
Main Parts List
*SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
*Grade : Parts Class”A,B,C,D,E”
