Samsung ML-1645

Service Manual
ExplodedView and Parts list
5-4
Samsung Electronics
Drawer# SEC_CODE DESCRIPTION QT’Y Service Grade Remark
5.1-7 JC96-05121A ELA HOU-FUSER 1 SA A 1640/110V
5.1-7 JC96-05122B ELA HOU-FUSER 1 SA A ML-1640/XIP
5.1-7 JC96-05124A ELA HOU-FUSER 1 SA A 2240/110V
5.1-7 JC96-05125A ELA HOU-FUSER 1 SA A 2240/220V
5.1-8 JC63-01930A SHIELD-ENGINE 1 SA B
5.1-9 JC39-00936A HARNESS-LSU 1 SA B
5.1-10 JC44-00109A SMPS-V1_VE 1 SA A 1640/110V
5.1-10 JC44-00110A SMPS-V2C_VE 1 SA A 1640/220V
5.1-10 JC44-00086A SMPS-V1 1 SA D 2240/110V
5.1-10 JC44-00087A SMPS-V2C 1 SA D 2240/220V
5.1-11 JC92-02027A PBA-MAIN 1 SA B
5.1-11 JC92-02018A PBA-MAIN 1 SA B
5.1-12 JC39-00937A HARNESS-MOTOR 1 SA B 1640
5.1-12 JC39-00932A HARNESS-MOTOR 1 SA B 2240
5.1-13 JC39-00400A CBF HARNESS-HVPS 1 SA A
5.1-14 JC39-00402A CBF HARNESS-SMPS 1 SA A
5.1-15 JC96-01672A ELA UNIT-TERMINAL TR L 3 SA D
5.1-15-1 JC61-00031A SPRING ETC--HV LARGE 1 SNA A
5.1-15-2 JC70-40912A ICT-SHAFT HV LARGE 1 SA D
5.1-16 JC44-00167A HVPS 1 SA A
5.1-17 JC63-00631A GROUND-P-HVPS 2 SNA A
5.1-18 3903-000042 CBF-POWER CORD 1 SA B 220V
5.1-18 3903-000085 CBF-POWER CORD 1 SA B 110V
5.1-19 3722-002303 JACK-USB 1 SA A
5.1-20 JC97-02239G MEA UNIT-MP TRAY 1 SA A 2240
5.1-21 JC31-00085A FAN-DC 1 SA A
Main Parts List
*SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
*Grade : Parts Class”A,B,C,D,E”
