Samsung ML-2250 Series User Manual

P RINTING T ASKS
4.29
4
Setting Up a Locally Shared Printer
Locally-Shared Printer
You can connect the printer directly to a selected computer,
which is called the “host computer” on the network. The printer
can then be shared by other users on the network through a
Windows 9x/Me/XP/NT 4.0/2000 network printer connection.
Printing Across a Network
Whether the printer is locally connected or network-connected,
you need to install the ML-2250 series printer software on each
computer that will print documents to the printer.
In Windows 9x/Me
Setting Up the Host Computer
1 Start Windows.
2 From the Start menu, select Control Panel, and double-
click on the Network icon.
3 Check the File and Print Sharing box, and click OK. Close
the window.
4 From the Start menu, select Printers from Settings and
double-click your printer name.
5 Select Properties in the Printer menu.
6 Click the Sharing tab and check the Shared As box. Fill in
the Shared Name field and click OK.
Setting Up the Client Computer
1 Right-click the Windows Start button and select Explorer.
2 Open your network folder in the left column.
3 Right-click the shared name and select Capture Printer
Port.

Samsung ML-2250 Series Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
First Print Out Time	Less than 10 seconds
Memory (Standard)	8 MB
Memory (Maximum)	72 MB
Duplex Printing	Manual
Paper Capacity (Standard)	250 sheets
Interface	USB 2.0, Parallel
Paper Capacity (Maximum)	500 sheets
Output Capacity	150 sheets
Media Sizes	A4, A5, Letter, Legal, Executive
Operating Systems Supported	Windows, Mac OS, Linux
Power Consumption	350W (Printing)
Print Speed	Up to 22 ppm (A4)
