SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are
thus subject to change without notice.
Technical Specifications
*: Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- Design and specifications are subject to change without prior notice.
- For information on the power supply and power consumption, refer to the label attached to the product.
RADIO
FM
Signal/noise ratio 62 dB
Usable sensitivity 10 dB
Total harmonic distortion 0.4 %
AM (Optional)
Signal/noise ratio 40 dB
Usable sensitivity 58 dB
Total harmonic distortion 1.5 %
COMPACT DISC PLAYER
Capacity 3 discs
Frequency range 20 Hz - 20 KHz (± 1 dB)
Signal/noise ratio 70dB (at 1kHz, with filter, 2V)
Distortion 0.1 % (at 1 KHz)
Channel separation 75 dB
Disc sizes Diameter: 120 or 80 mm. Thickness: 1.2 mm
AMPLIFIER
Output power
MX-D830-
560 Watts (10% THD)
Front Speaker 280W/CH (6 Ω/100Hz)
MX-D830-
640 Watts (MAX. THD)
Front Speaker 320W/CH (6 Ω/100Hz)
MX-D850-
760 Watts (10% THD)
Front Speaker 280W/CH (6 Ω/100Hz)
Subwoofer 200W/CH (8 Ω/100Hz)
MX-D850-
860 Watts (MAX. THD)
Front Speaker 310W/CH (6 Ω/100Hz)
Subwoofer 240W/CH (8 Ω/100Hz)
MX-D870-
1,200 Watts (10% THD)
Front Speaker 270W/CH (6 Ω/100Hz)
Subwoofer 200W/CH (8 Ω/100Hz)
Rear Speaker 130W/CH (12 Ω/15kHz)
MX-D870-
1,400 Watts (MAX. THD)
Front Speaker 300W/CH (6 Ω/100Hz)
Subwoofer 250W/CH (8 Ω/100Hz)
Rear Speaker 150W/CH (12 Ω/15kHz)
Channel separation 60 dB
Signal/noise ratio 70 dB
GENERAL
Dimensions (MX-D830/MX-D850) 294 (W) x 379.8 (H) x 436.8 (D) mm
Dimensions (MX-D870) 294 (W) x 398.8 (H) x 436.8 (D) mm
Weight (MX-D830/MX-D850) 5.8 Kg
Weight (MX-D870) 6.2 Kg
