Disassembly and Assembly
20
Battery Remove
1 Using tweezers, remove the Kapton tape on the battery connector and separate it.
Keep the Kapton tape to reuse it for assembly.
2 Using a cross-head screwdriver, remove the 4 screws on the battery and separate it.
Be careful not to damage the near components.
Check the number of screws that have been removed, and store them carefully
to make sure that no unassembled screws are left inside the computer during
assembly.
After you finish disassembling, refer to Battery Assembly for how to reassemble.
